Specifications
China 10w 110x110mm fiber laser marking device1.10w Fiber laser
2. Air cooling
3. 110x110mm mark scope
China 10w 110x110mm fiber laser marking device
Portable type:
Desktop type:
Features:
1. Very small, friendly interface, the information display will be the subject of marking information.
2. Imported high-quality, high-energy, stable fiber laser machine, speedy precision optical galvanometer and industry-leading software system.
3. Compact structure, hard, light, small, simple interface, flexible and adjustable process direction, control freely.
4.Can print number, letter, Chinese characters, signs, graphs, images, bar codes, two-dimensional codes, serial numbers random number, batch number, add code, production date, valid date, any self-creative character.
5. Adopts intelligent laser dot matrix coding technology, through software adjustment: parameters of Lattice space distance, size of laser power and laser dwell time, improve the coding flexibility. Well adapt to online packing code marking need in all kinds of industry.
6. Easy to maintenance.
7. Whole machine adopts modular design, no consumption parts, improve self-diagnostic system, save time, effort, and worry in maintenance.
Application:
1; can be engraving metal and a variety of non-metallic materials. Some of the requirements are more suitable for fine, high precision processing.
2; used in electronic components, integrated circuits (IC), electrical appliances, communications, hardware, tools, accessories, precision instruments, eyeglasses and clocks, jewelry, auto parts, plastic buttons, construction material, PVC pipe, medical equipment, etc. .
3; application materials include: ordinary metals and alloys (iron,steel, copper, aluminum, magnesium, zinc and all other metals), rare metals and alloys (gold, silver, titanium), metal oxide (metal oxide may be), special surface treatment (phosphate, aluminum anodizing, plating surface), ABS material (electrical appliances, housing, commodities), ink (translucent button, print products), epoxy resin (electronic components, packaging, insulation layer.
Configuration:
Name |
Remarks |
Optical laser |
Long service life, high reliability, fine beam quality |
Galvo mirror(Laser head) |
Fine marking, more quick and high reliability |
F-θ lens |
High quality optical device(you can choose 110*110mm 200*200mm 300*300mm) |
Marking software |
Powerful, simple and convenient operation, Auto-cad, Coreldraw, Photoshop software compatible format |
Control computer |
Industrial Computer |
Control cabinet |
Optical fiber special cabinet, all the mold production, high seal |
Technical parameter:
Type specification |
SK-FP10 |
SK-FP20 |
SK-FP30 |
SK-FP50 |
Wave length of laser |
1064nm |
|||
Laser repetition frequency |
20kHz~100kHz |
|||
Laser power |
10W |
20W |
30W |
50W |
Marking scope |
70*70 /100*100 /200*200mm/300*300mm |
|||
Laser sources |
Fiber module |
|||
Laser Head |
Scanning head |
|||
The minimum focus facula diameter |
20μm |
|||
Minimal character |
0.01mm |
|||
Marking speed |
≤7000mm/s |
|||
Repeated accuracy |
0.0025mm |
|||
Cooling ways |
Force-air Cooling |
|||
Power supply |
220V/ 50Hz/2kVA |
|||
Gross weight |
65KG |
65KG |
65KG |
65KS |
Volume |
1m3 |
1m3 |
1m3 |
1m3 |
Process Material |
All kinds of metal and part of Non-metal Materials |
|||
Support format |
PLT, BMP, DXF, JPG, TIF, AI etc |
|||
Package |
Standard Crate for export |
|||
The whole machine include |
LCD display, controller box ,laser systems, |
|||
Configuration |
Coaxial red light position system Up & down worktable |
|||
Accessory box |
Microsoft dog, quality certificate etc |
|||
Our sales at Shanghai Exhibition
ble fiber laser marking machine
