Specifications
high speed laser machine with motorized platform1.Working Area:900*600 mm
2.laser type: sealed CO2
3.Power: 80w or 100w
high speed laser machine with motorized platform
Appliacble materials :
Our laser machine is suit for wood , die board, MDF ETC hard wood cutting works. cutting thickness 1-3cm.Tt also suit for fabrics, label, paper boards, leather, embroidery, acrylic ,wooden plates and paper ware etc non-metal material.
Product Specification:
Model |
Laser cutting machine SK900 |
Working area |
900*600mm |
Laser tube power |
40W/60W/80W/100W(can be optional) |
Laser tube type |
Sealed CO2 laser tube, water-cooling, 10.6um |
Life of laser tube |
1500 hours |
Max Engraving speed |
0-60000mm/min |
Cutting speed |
0-30000mm/min |
Cutting thickness |
1-20mm acrylic (others determined by the material ) |
Resolution ratio |
<0.01mm |
Location precision |
<0.01mm |
Min shaping character |
Chinese 2*2mm,English1*1mm |
Support graphic format |
DST, PLT, BMP.HPGL,DXP and AI |
Software supported |
CorelDraw, AutoCAD, Photoshop |
Power supply |
AC110-220V 50-60HZ |
Operating temperature |
0– 40 centigrade degrees |
Operating humidity |
5%-95% Free of condensed water |
Interface |
USB |
Assistant equipment |
Exhuast-fans, water pump, air pump |
Driving system |
stepper |
Control system |
DSP |
Consuming power |
<1,000W |
Net weight |
370kgs |
Gross weight |
380kgs |
Package size |
187*112*130cm |
Features:
- Front and rear hole to pass long materials
- Modern design and beautiful appearance
- Use imported Taiwan Hiwin linear guide, more durable and high precision
- Water protection switch ,safety switch and limit switch
- Adopt DSP control system, and USB offline operation,LCD screen
- powerfull production ability,can produce all kinds of laser machines, like double head laser , four head laser ,CCD camera laser,auto feeding fabric laser cutter,YAG metal laser engraver,separate marble laser etc.
Samples:
Spare parts:
Wish to have a coopertion with you sincerely,Thank you.
