Specifications
Automatic Tool Change CNC Router SK-M251.6kw water cooling spindle
2. Janpan YASKAWA servo system
3.Taiwan Syntec Sytem
Automatic Tool Change CNC Router SK-M25
Product Overview
SK ATC CNC Router series are at the service of High-end customers with high demand in automation, for its application suitable to 24 hours mass production. All the configuration are in high-end configuration for best performance and best quality and efficiency.
Technical Parameter
Model |
SK-M25-I |
SK-M25-I |
Optional Part |
Working area (X,Y,Z mm) |
1300x2500x200 |
Customization available |
|
Machine structure |
Square tube structure lathe bed and vacuum table |
Vaccuum table with T-slot |
|
Tool Magazine |
Line type, 6pcs |
Carrousel type, 6pcs |
8/10pcs |
Working holding |
By vacuum |
By vacuum and clamps |
|
Overall Dimensions (mm) |
3300*2250*2000 |
|
|
Precision (mm) |
0.07 |
|
|
Positioning accuracy(mm) |
0.02 |
|
|
Repeatability(mm) |
0.02 |
|
|
Idling Speed(mm/min) |
30,000 |
|
|
Working Speed (mm/min) |
20,000 |
|
|
Spindle |
6kw water cooling (0~24000rpm) |
Air cooling(0~18000), any kw |
|
Available Tools (mm) |
Diameter 3.175-12.7mm |
|
|
Drive system |
Japanese YASKAWA Servo System |
Panasonic |
|
Working Voltage |
AC380V±30V,50HZ |
|
|
Command code |
G code (*.NC,mmg,*.u00,etc)*.eng |
|
|
Control System |
Taiwan Syntec System |
Taiwan LNC System or NcStudio |
|
Compatible Software |
Compatible with any softare generating G code file in Windows 98/XP/7 |
|
|
Product Feature
- Heavy-duty thick-walled square tube lathe in good rigidity, is capable of large workload, maintaining solid shape and non-deformed.
- High-end CNC control system from Taiwan, automated intelligent control on function , such as work area protection, processing cross-border protection, auto working speed. Off-line operation of multiple levels of 3d processing is capable.
- Advanced documents pre-processing functions ensures speed and accuracy of operation.
- Control panels of 7’ Led, multi-partition keyboard provide convenience and independence for user.
- Automatic tool changer saves time for manual tool changing to improve efficiency.
- Servo system from Japan is the core of drive system, with a large torque and complete security system.
Scope of application:
Wood Products Processing: Sewing machine table, electrical counter table, sports equipment.
Furniture Decoration Industry: a large area flat plate engraving, wood, panel furniture carving, wood art murals, wood cabinet doors curving.
Musical Instrument Industry: Instrument three-dimensional surface engraving, shape cutting.
Electronic Industry: Circuit board, insulation materials, LED display screen.
