Specifications
woodworking cnc router kit1.6kw water cooling spindle
2.Stepper motor
3.DSP Control Sytem
woodworking cnc router kit
Product Overview
This machine is at the service of customers who requires 2~4 tools in one processing. It saves time for manual tool changing, improves production efficiency, reduces the cost of purchase and has much lower request on operation.
Technical Parameter
Model |
SK-M25X |
Working area (X,Y,Z mm) |
1300x2500x200 |
Machine structure |
Square tube structure lathe bed and vacuum table |
Working holding |
By vacuum |
Overall Dimensions (mm) |
3100*2050*1650 |
Precision (mm) |
0.07 |
Positioning accuracy(mm) |
0.02 |
Repeatability(mm) |
0.02 |
Idling Speed(mm/min) |
35,000 |
Working Speed (mm/min) |
25,000 |
Spindle |
6kw water cooling (0~24000rpm) |
Available Tools (mm) |
Diameter 3.175-12.7mm |
Drive system |
Stepper motor |
Working Voltage |
AC380V±30V,50HZ |
Command code |
G code (*.NC, mmg,*.u00,etc)*.eng |
Control System |
DSP System |
Compatible Software |
Compatible with any software generating G code file in Windows 98/XP/7 |
Product Feature
- Alternate work of multi-head achieves rapid auto tool changing, saving time of manual tool changing for higher process speed and precision.
- Simultaneous work of multi-head may carve several same patterns at same time to enhance the work efficiency.
- Spaces between spindles can be adjusted to different materials in bulk.
- 6.0kw Air-cooled spindle with longer life, cooling without water.
- Advanced DSP controller, convenient for tool setting and travel control.
Spare Parts
Scope of application:
Wood Products Processing: Sewing machine table, electrical counter table, sports equipment.
Furniture Decoration Industry: a large area flat plate engraving, wood, panel furniture carving, wood art murals, wood cabinet doors curving.
Musical Instrument Industry: Instrument three-dimensional surface engraving, shape cutting.
Electronic Industry: Circuit board, insulation materials, LED display screen.
Sample Display
