Help CenterWood Pattern CNC Engraving Machine
Related Products
Specifications
wood pattern CNC engraving machine1.DSP system
2.CE
3.Type 3 software
wood pattern CNC engraving machine
Technical paramters:
Model |
CNC router SK1325 |
XYZ working area |
1,300 x 2,500 x 200mm |
Table size |
1,500 x 3,000mm |
XY movement |
Gear wheel |
XYZ traveling positioning accuracy |
±0.03/300mm |
XYZ repositioning positioning accuracy |
±0.02mm |
X,Y Working Delicacy |
<0.01mm |
Resolutions |
0.05mm |
Max. Consume power |
about 4.0Kw |
Max. Speed |
0-32000 mm/min |
Max. Working Speed |
0-25000 mm/min |
Spindle |
2.2kw |
Spindle Power Motor |
2.2 kw BOL High speed air cooling spindle motor ,Italian technial ,fast seed and high quality ,18000RPM |
Spindle Speed |
18000RPM |
Working model |
Stepper model |
Control system |
DSP |
Command language |
G code |
Working voltage |
AC380V/50-60Hz, 3-phase |
Interface |
Printer port 50pins or USB |
system Memory |
a large USB flash disk |
Linear guide |
Square linear guide From Taiwan |
Optional devic |
dust collector, Vacuum system , servo system(will use Panasonic servo motors and driver board) , |
Software supported |
Type3 software, wentai software |
Operation circumstance |
Temperature: 0°C~45°C |
Net weight |
900kgs |
Gross weight |
1000 KGS |
Package size |
330*185*180cm |
Samples:
Features:
1).Adopting advanced DSP system, operated with the handle, convenient operation, designed with more human nature.
(2).High power driver and motor, dual-motor drive, a unique dual-axis drive tooth strength of the large, smooth transmission, high-speed operation of the guarantee is not a long time deformation, jitter.
(3).Unique intelligent budget principle , fully develops the potential of the motor and lead to high processing speed, the synchronization of curves and straight lines, smoother curves.
(4).Fast speed, high efficiency, air speed up to 8 m / min
(5).With 6 individual vaccum zone
(6).Oil lubricating system improve service life of machine
(7).well compatibility compatible software CAD/CAM, like Type3/artcam/coreldraw and other software.
(8).perfect cooling system, effectively improved the tool’s life and maintenance system
(9)Mainly used for production of closet doors, solid wood processing, furniture, etc. Also can be used for cutting and production of MDF.
Wsih you contact with me directly if any interested.
