Plastic Pallet Blow Molding Machine

Plastic Pallet Blow Molding Machine thumbnail-1
Plastic Pallet Blow Molding Machine thumbnail-2
Plastic Pallet Blow Molding Machine thumbnail-3
Plastic Pallet Blow Molding Machine thumbnail-4
Plastic Pallet Blow Molding Machine thumbnail-5
Plastic Pallet Blow Molding Machine thumbnail-6
Plastic Pallet Blow Molding Machine photo-1
Plastic Pallet Blow Molding Machine photo-2
Plastic Pallet Blow Molding Machine photo-3
Plastic Pallet Blow Molding Machine photo-4
Plastic Pallet Blow Molding Machine photo-5
Plastic Pallet Blow Molding Machine photo-6
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Other, Storage Water Tank
Plastic Processed:
Other, HDPE HMWHDPE, HMHDPE HDPE
Contact Supplier Request Quote Chat Now
Qingdao Yankang Plastic Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Other, Storage Water Tank
Plastic Processed Other, HDPE HMWHDPE, HMHDPE HDPE
Blow Moulding Type Extrusion Blow Moulding
Automatic Other, Yes, Touch Screen
Place of Origin Shandong, China
Brand Name YanKang
Model Number YK-3000L-3
Power(W) 350KW
Dimension(L*W*H) 12*4.5*7.2M
Weight 65Ton
Certification SGS
Warranty 1 YEAR, One Year
After-sales Service Provided Engineers available to service machinery overseas
Product Description

 Parameters



No



specifications

3000 Liter


Model No.

3 layers





PRICE FOB QINGDAO







Processing material

HDPE/HMWHDPE

1

Extruders

Screw Diameter (Internal)

110mm grooved barrel





Screw Diameter(Middle school)

110mm grooved barrel





Screw Diameter (Outer Layer)

110mm grooved barrel





Plasticizing Capacity

550kg/h





L/D

L/D32:1





Gear Box Type

Hard surface





Extruder Drive Motor (Inner)

75kw





Extruder Drive Motor (Middle)

75kw





Extruder Drive Motor (Outer )

75kw





Heating Load

110KW





Max Screw Speed

60RPM

2

Accumulator Die Head

Accumulator capacity

180L





Pusher Cylinder

650x600mm





Heating Load

115KW





Parison Control Cylinder

560X40mm





Die-Core size [ Min / Max]

300-700MM





Inverter

Siemens





Max. parison weight

80KG

3

Moulding Clamping Unit

Max opening between Clamping Plate

3500mm





Min opening between Clamping plate

1000mm





CLAMPING PLATEN Size

2100x2200mm





MAX MOLD SIZE

1900*2300Mm





Mould Clamping Force

2200KN





Mould Thickness

1000-2200





Clamping Pull Bar

150mm

4

Stretching and Blowing Unit

Spreading stroke

450-1300mm





Vertical stroke max.

350mm

5

Electrical Control Panel

Thickness controller

100 points Moog





Main Operation Panel

Siemens





Die Head Control Temperature Control

Siemens

6

Hydraulic System

Hydraulic Drive motor (Main)

45KW





Hydraulic Drive Motor (Parison Control)

7.5kw





Oil Tank Capacity

1200L

7

Gripper

Gripped stroke

350mm





Discharge Stroke

2400mm

8

Hopper Loader

Loader

800kg 3pcs





Hopper

50kg 3pcs

9

Production rate

Productivity

5pcs/h



of 1000 ltr.

Product Weight

75-90kg

10

Delivery period



5 months

11

Weight of Machine



65Ton


Size of Machine

[L xW xH ] (M)

12*4.5*7.2

12

Total power



350KW

13

Average power Consumption



250KW
Our Services

DELIVERY TIME

4 months after the down payment;



TRAINNING

The Buyer could dispatch their operators to the Seller's factory for training, including machine operation, maintenance & simple repairs;

Or against the requests of the Buyer, the Seller's technician could train the Buyer's operators in the Buyer's factory in the periods of installing & adjusting;

The training is free of charge;



INSTALLATION & ADJUSTMENT

The Seller could dispatch an engineer against the requests of the Buyer to install and adjust the machines for one week in the Buyer's factory.

The Buyer should make a reservation in advance before delivery of the machines;

The Buyer should pay for the engineer's food & board while installation in buyer's factory.



GUARANTEE

The guarantee time is one and half year after the machines normally works in the Buyer's factory, if only the problem is cause due to quality control or any reason by the Seller. We will supply replaced parts free of charge and our engineers will guide you how to solve the problems.

Any problem caused due to irregular operation or incorrect maintenance by the Buyer won't be listed in guarantee coverage.
