3 phase online ups 10kva 15kva 20kva

Specifications

1. 3 phase online ups
2. Rated power 10kva 15kva 20kva
3. True sine wave output
4. Led/Lcd display
5. back up power

3 phase online ups 10kva 15kva 20kva



Main feature



• True on-line double conversion technology with advanced microprocessor control
• Wide input voltage range with high frequency technology
• Zero transfer time
• Protection against all type of power problems
• Self test while start of the UPS
• Site wiring fault warning
• On-battery power-on function
• Smart RS232 communication interface
• Intelligent slot available
• Sealed acid battery, free-maintenance battery



Pictures











Description



Output	C1KVA/C1KS	C2KVA/C2KS	C3KVA/C3KS
Rated Power	1000VA/700W	2000VA/1400W	3000VA/2100W
Output Voltage	208VAC/220VAC/230VAC/240VAC
Voltage Waveform	Pure Sine wave
Crest Factor	3:1
Output Frequency (Synchronized- Mains)	46~54Hz or 56Hz - 64Hz (Line mode) 50/60HZ/ ±0.05Hz( Battery mode)
Regulation(Nominal)	±1%
Regulation (Battery mode)	±1%
Transfer time	0 ms; less than 4 ms from inverter to bypass and vice versa
Over current protection	Line Mode:10min@100%~130%; Battery Mode:30s@100%~130%
Outlet	IEC*4/IEC*6/IEC*4+Terminal
Harmonic Distortion	≤2%THD(Linear Load); ≤5%THD(Non-Linear Load)

2.Input

Input	C1KVA/C1KS	C2KVA/C2KS	C3KVA/C3KS
Nominal Voltage	160~300VAC@full load (110~300VAC@half load)
Input Frequency	46~54Hz / 56~60Hz
Efficiency	87% (AC mode)/83%(Battery Type)
Noise Filtering	Full time EMI/RFI filtering
Over current protection	by AC fuse or by re-settable over current   protector

AVR Range (2 Bucks,2 Boosts)	Enhanced Buck: +15% of selected nominal voltage Buck mode: +5% of selected nominal voltage Boost mode: -5% of selected nominal voltage Enhanced Boost: -12.5% of selected nominal voltage
Phase	Single phase with ground

3.Battery

Battery type	Sealed lead acid Battery
Rated Charging Voltage	41.0Vdc / 81.9Vdc / 109.2Vdc
Typical backup time	more than 5 min
Charging method	Smart pulse charging with two charging modes. Quick charging when battery is not fully charged, trickle charging when battery is 90% fully charged.
Charging current(MAX)	1.0A(C1KS-C3KS:4.0/8.0A)
Protection	Over current protection & Over charging voltage protection (SCR control) Thermal protection (CPU control) When temperature inside UPS is over 45°C,  charger will stop charging for 2.5 minutes followed by an 1.5 minutes charging.     The cycle will be repeated until the temperature is lower than 44°C.
TemperatureCompension	Yes
Numbers of Batteries	3	8	8

4.Optional Features

ECO Mode	Support
CVCF	Support
PDU	Support
Remote Panel	Wired Type,Up to 100M Length

Parallel Redundancy

Up to 4 Units maxium(Option)

5.Environmental and Safety

Operating Temperature	0°C to 40°C (32°F to 104°F)
Transit/storage Temperature	-15°C to 55°C (5°F to 131°F)
Relative Humidity	20-90%(NON-CONDENSING)
Operating Altitude	0 ~ 3000 meters
Audible noise	less than 50 dBA
Safety Markings	BSMI	CE
EMC	Class B, EN50091-2, FCC part15, IEC1000-2-2
Quality control system	ISO 9001:2000
Noise Level	less than 55db@1 Meter

LED Version	Load Level/Battery Level/Battery;Mode/AC Mode/Bypass Mode/Fault
Battery Mode	Sounding every 4 seconds
Low Battery	Sounding every second
Overload	Sounding twice every  second
Fault	Continously Sounding
LCD Version	Load/Battery/Input/Output/Operating;Mode Information

6.Indicator Interface

Smart RS-232	Software supports Windows Family. Sun Solaris,IBM Aix,Compaq True64, SGIIRIX ,FreeBSD.HP-UX,and MAC
USB (Option)	Windows Family& MAC
Internal Slot(Option)	SNMP/AS400 Relay Card/Rs485
EPO(Option)	Support Emergency Shutdown

7.Physical

Dimensions:  (D×H×W)mm	400*145*220	460*192*348	460*192*348
N.W/G.W(kg)	1KVA:14 / 1KS:7	2KVA:34 / 2KS:13.5	3KVA:35 / 3KS:14
Packing	PBP standard Packing,Export carton for each unit



 Typical Application



Server, Data center, Critical network devices, Sensitive electronic equipment, Telecom
