192v Pure Sine Wave UPS 6000va With Charger

Name: 192v Pure Sine Wave UPS 6000va With Charger
Brand: Must Solar
SKU: 128026503
Availability: InStock

192v Pure Sine Wave UPS 6000va With Charger thumbnail-1

192v Pure Sine Wave UPS 6000va With Charger photo-1

US$ 360 - 490 MOQ: 5 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

Must Solar

Model Number:

C6K

Contact Supplier Request Quote Chat Now

Shenzhen Must Solar Power Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

FOB shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name Must Solar

Model Number C6K

Phase Single Phase

Protection Unbalanced Loads

Weight 24.5KG

Output Voltage 110v/220v

Type On-line

Application Networking

Specifications

1.UPS 6000va 230v
2.LCD/LED
3.output power factor is 0.8
4.Pure Sine wave output
5.double conversion

1. Features

True on-line double conversion technology with advanced microprocessor control
Wide input voltage range with high frequency technology
Zero transfer time
Protection against all type of power problems
Self test while start of the UPS
Site wiring fault warning
On-battery power-on function
Smart RS232 communication interface
Intelligent slot available
Sealed acid battery, free-maintenance battery

2. Data Sheet

Output	C6KVA/C6KS	C10KVA/C10KS
Rated Power	6000VA/4200W	10000VA/7000W
Output Voltage	208VAC/220VAC/230VAC/240VAC
Voltage Waveform	Pure Sine wave
Crest Factor	3:1
Output Frequency (Synchronized- Mains)	46~54Hz or 56Hz - 64Hz (Line mode) 50/60HZ/ ±0.05Hz( Battery mode)
Regulation(Nominal)	±1%
Regulation(Battery mode)	±1%
Transfer time	AC to DC :Zero Inverter to Bypass: Zero
Over current protection	Line Mode:10min@100%~130%;Battery Mode:30s@100%~130%
Outlet	Hard Wiring with Terminal Block
Harmonic Distortion	≤2%THD(Linear Load);≤5%THD(Non-Linear Load)

2.Input

Nominal Voltage	160~300VAC@full load (110~300VAC@half load)
Input Frequency	46~54Hz / 56~60Hz
Efficiency	90% (AC mode) 90%(Battery Type)
Noise Filtering	Full time EMI/RFI filtering
Over current protection	by AC fuse or by re-settable over current protector

AVR Range (2 Bucks,2 Boosts)	Enhanced Buck: +15% of selected nominal voltage Buck mode: +5% of selected nominal voltage Boost mode: -5% of selected nominal voltage Enhanced Boost: -12.5% of selected nominal voltage
Phase	Single phase with ground

3.Battery

Battery type	Sealed Lead Acid Battery
Rated Charging Voltage	220.8Vdc
Typical backup time	>5min
Charging method	Smart pulse charging with two charging modes. Quick charging when battery is not fully charged, trickle charging when battery is 90% fully charged.
Charging current(MAX)	1.0A(6KS,10KS:4.0/8.0A)
Protection	Over current protection & Over charging voltage protection (SCR control) Thermal protection (CPU control) When temperature inside UPS is over 45°C,charger will stop charging for 2.5 minutes followed by an 1.5 minutes charging. The cycle will be repeated until the temperature is lower than 44°C.
Temperature Compension	Yes
Numbers of Battery	20

4.Optional Features

ECO Mode	Support
CVCF	Support
PDU	Support
Remote Panel	Wired Type,Up to 100M Length

Parallel Redundancy

Up to 4 Units maxium(Option)
Up to 4 Units maxium(Option)

5.Environmental and Safety

Operating Temperature	0°C to 40°C (32°F to 104°F)
Transit/storage Temperature	-15°C to 55°C (5°F to 131°F)
Relative Humidity	20-90%(NON-CONDENSING)
Operating Altitude	0 ~ 3000 meters
Audible noise	Less than 50 dBA
Safety Markings	BSMI	CE
EMC	Class B, EN50091-2, FCC part15, IEC1000-2-2
Quality control system	ISO 9001:2000
Noise Level	<60dB@1 Meter

6.Indicator

LED Version	Load Level/Battery Level/Battery;Mode/AC Mode/Bypass Mode/Fault
Battery Mode	Sounding every 4 seconds
Low Battery	Sounding every second
Overload	Sounding twice every second
Fault	Continously Sounding

7.Interface

Smart RS-232	Software supports Windows Family.Sun Solaris, IBM Aix,Compaq True64,SGIIRIX ,FreeBSD.HP-UX,and MAC
USB (Option)	Windows Family& MAC
Internal Slot (Option)	SNMP/AS400 Relay Card/Rs485
EPO(Option)	Support Emergency Shutdown
