2014 Chinese CE machines new products potato shredder

Specifications

potato shredder
1for large pipe,thick plastic wasted material crushing
2High capacity
3Safty



 Sammary for   bottle shredder :

2 shaft shredder is named shear type shredder too. It reduce the dimension of the material through cutting, tearing and extruding. It provides a good quality and reliable equipment for early broken of the waste recycling and volume reduction treatment.
Double shaft shredder is widely used in waste plastic, waste rubber, wood and other big block waste broken.



What kind of plastics  we can work with  pp / pe film shredder machine  ?



Features of pp / pe film shredder machine  :

a.The double shaft shredder are new designed especially for crushing the film in rolls, tires of cars

 and medium sized automobiles, hollow barrels and so on.

b.The shredders have the characteristics of strong crushing ability and contrarotation with the

structure of close-lined rotary knives in double direction.



c.With Simense PLC control system.





Flow chart Drawing for pp / pe film shredder machine   :



Specfication for various models   pp / pe film shredder machine :

Modle	600A/B	800A/B	1000A/B	1200A/B	1400A/B	1600A/B
Motor power(kw)	11-6 Or 15-4	22 or 30	37 or 45	55-6	45-6×2	55-6×2
Rotating speed(rpm)	50	50	20	20	30	30
Rotary diameter(mm)(single)	300	320	400	450	500	520
Knife material	special tool steel	special tool steel	special tool steel	special tool steel	special tool steel	special tool steel
Knife thickness(mm)	50	50	50	70	70	70
Knives quantity	12 rotary 12 fixed	16 rotary 16 fixed	20 rotary 20 fixed	17 rotary 17 fixed	20 rotary 20 fixed	22 rotary 22fixed
Output(kg/h)	600-800	800-1000	1200-1500	1600-2000	2000-2500	3000-4000



 Photo performance for can shredder  :



CE certificate for   box shredder  :



Our main suppliers:

Loading time:
