Professional subwoofer stage powered line array for sound system
The active line array loudspeaker range is ideal for sound reinforcement system for meeting room, concert, outdoor party, auditorium & stadium etc.
* Versatile installation for conference room, auditorium, stadium, concert & bar.
* Easy plus-in installation and use.
* Minimum cable wiring and low cost of maintenance.
* Supply with secure steel ring for easy installation.
* Built-in 85% high efficient class-D amplifier with better sound restoration and highestReliability.
Model |
LA-2650P |
LA-2800P |
LA-1200P |
LA-1800P |
Description |
Two way active line array loudspeaker |
Two way active line array loudspeaker |
Active Subwoofer |
Active Subwoofer |
Rated power ouput |
150W (AES) |
300W(AES) |
350W (AES) |
500W(AES) |
Output Impedance |
6Ω |
8Ω |
8Ω |
4Ω |
Frequency Response(-10dB) |
85Hz-20KHz |
70Hz-20KHz |
45Hz-800Hz |
40Hz-800Hz |
Sensitivity(1W@1M) |
99dB |
100dB (1M/1W ) |
99dB |
100dB (1M/1W) |
Line input sensitivity |
0dB |
0dB |
0dB |
0dB |
Speaker Type |
6.5" x 2 |
8" x 2 |
12" x 1 |
18" x 1 |
Tweeter |
34mm(1.34") 1x compression driver |
44mm (1.73") 1x compression driver |
/ |
/ |
Horizontal Dispersion Angle(-6dB) |
90° |
90° |
/ |
/ |
Vertical Dispersion Angle(-6dB) |
Change according to the linear array |
Change according to the linear array |
/ |
/ |
|
size and Angle |
size and Angle |
|
|
Net Weight |
17.8kg |
28.2kg |
30.9kg |
42.9kg |
Gross Weight |
20.1kg |
30.5kg |
35.1kg |
44.1kg |
Dimension(WxDxH) |
(230+150) x 290 x 620 mm |
(300+195) x 380 x 750 mm |
400 x 450 x 620 mm |
550 x 600 x 750 mm |
Other kinds of Line array speakers
ITC promise the electronics yearly failure rate is less than 1%.
ITC guarantee all electronics of 3 years quality warranty.
ITC could supply 1% wearing spare parts free of charge.
ITC guarantee all loudspeakers of 6 months quality warranty.
All of quality complaint shall be attached with serial number, failure test report and photos.
All of the quality compliant shall be feedback with a solution within 48 hours.
ITC could supply circuit diagram documents for repair.
- Well-trained sales team for sales and basic technical service.
- New product promotion and seminar for all employees.
- Two English spoken technician provide online after sales service.
- Online system software demo and configuration is available.
- 30 system consultants and 10 designers to make drawing and BOQ for each tender.
- Design and BOQ response to customer within 48 hours.
- PDF specification sheet, system configuration template and architectural & engineer specification for documents support.
- Technical documents could be downloaded from website
