Public Address 5 Channel creative Speaker Volume Control
* 5 channel separate volume control
* Rack mounted design in 1U height
* Built-in relay
* An override feature is provided to disable the volume control settings in case of an emergency
* 5 channels inputs and outputs
* 5 independent channels, 200 watts per channel, total 1000W control capacity
* 5 steps attenuation
* Convenient and fast remote control the zone volume
* Frequency response from 100 Hz to 16 KHz while distortion less than 1.5dB
* DC 24V interface
Model |
T-6239F |
Power Output |
200 watts*5 |
Inputs |
5 channels |
Outputs |
5 channels |
Frequency Response |
100 Hz to 16 KHz( 1.5dB) |
Output Level |
0V~100V |
Input |
100V |
Relay |
DC 24V |
Power Consumption |
5W |
Weight |
4.6Kg |
Dimensions |
484x209x44mm |
ITC promise the electronics yearly failure rate is less than 1%.
ITC guarantee all electronics of 3 years quality warranty.
ITC could supply 1% wearing spare parts free of charge.
ITC guarantee all loudspeakers of 6 months quality warranty.
All of quality complaint shall be attached with serial number, failure test report and photos.
All of the quality compliant shall be feedback with a solution within 48 hours.
ITC could supply circuit diagram documents for repair.
