Wireless Conference IR Communication System Wireless Digital Audio Controller TH-0500M
Feature of Wireless Digital Audio Controller TH-0500M :
- Digital conference system master controller
- Infrared wireless transmission technology
- Control data of tunning frequency transmission technology
- Capacity of 128 microphone system
- Discussion feature meeting system
- No cable wiring for saving cost
- Excellent sensitivity microphone capsule to ensure superior sound restoration
- Discussion modes: limited and by turn modes
- External connection with auto video tracking system
- Built-in LCD screen to display parameter and working status
- Two aux outputs for sound reinforcement system and voice recorder
- 19" standard rack mount design
- Design according to UL and CE standard
Specification of Wireless Digital Audio Controller TH-0500M :
Model |
TH-0500M |
Audio channels |
4 channels |
communication mode |
Wireless infrared communication |
Number of channels |
4 channels |
Frequency range |
6MHz-8MHz |
Modulation Mode |
FM |
Receiver Sensitivity |
-85dBM |
Output Level |
-10dB |
Frequency response |
100Hz-10KHz |
Signal to noise ratio |
>70dB |
Distortion |
<0.5% |
Infrared transmission distance |
>10m |
Control channel |
|
Communication mode |
Wireless communication |
Number of channels |
5 |
Frequency range |
915MHz-925MHz |
FSK Modulation |
FSK |
Receiver Sensitivity |
-80dBM |
Transmitting power |
10dBM (adjustable) |
Rate |
100KBPS |
Signal coverage |
100m (Radius) |
System |
|
Power |
AC110V-220V/50/60Hz |
Power |
10W |
Operating Temperature |
0°C-40°C |
Dimension |
484×377×85mm |
Weight |
6.81Kg |
