Help CenterStainless Steel Butterfly Valve
Negotiable
MOQ: 100 Sets (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Structure:
Butterfly
Pressure:
Medium Pressure
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Standard or Nonstandard
Standard
Structure
Butterfly
Pressure
Medium Pressure
Power
Manual
Material
Casting
Temperature of Media
Normal Temperature
Media
Water
Port Size
DN50( 2")-DN1000( 48")
Place of Origin
Tianjin, China
Model Number
Wafer Butterfly Valve
Brand Name
OEM
Specifications
Stainless Steel Butterfly Valve Size: DN50(2")~DN1000(48") Working Temperature: -15 degree~135 degree Applicable Medium: WaterStainless Steel Wafer Butterfly Valve Size: DN50(2")~DN1000(48") Working Temperature: -15 C degree~135 C degree Applicable Medium: Water, Steam, Oil, Acid, Salt, etc.
1. Design Standard: API 609
2. Face to Face: API609; DIN3202-K1; ISO5752
3. Body Flange Drilling: DIN2501 PN10/PN16; ANSI125/150; BS4504; JISB2210 10K
4. Top Flange: ISO5211
5. Standard: DIN, ANSI
6. Body: Cast iron, ductile iron, WCB, S. S304, S. S316, bronze
7. Disc: Ductile iron, SS304, SS316
8. Seat: EPDM, NBR, PTFE, Viton
9. Shaft: 45# steel, SS416, SS304, SS316
10. Disc with pin or without pin
11. Pressure: PN16, 150lbs
12. Operator: Lever, gearbox, pneumatic, electric
13. Certificate: CE and ISO
