64 Channel Dual Streaming PC Based DVR:HK-DVR264H

Specifications

64 Channel Dual Streaming PC Based DVR:
1)1600fps(P)/1920fps(N)
2)Intel P4 2.66G CPU or above
3)H.264 Compression

64 Channel Dual Streaming PC Based DVR:



64chs video and audio, 1600fps(P)/1920fps(N)

Compress Card: H.264 DS-4016HCI Hardware compress

CPU Intel P4 2.66G CPU or above

Main BoardGA-945PL-S3E or above

MemoryKingSton 1G DDR400 or above

H.D.D:MAXTOR 250G*2/7200

Display Card:128M ATI or above

DVD Writer:16X Samsung

Case:Industrial Case



Server Features:


DVR System:

• 1-64 channels video and audio input


• Each channel can be compressed independently


• Dual display operation for live monitoring and playback on two monitors


• OSD & LOGO adjust position freely


• Support IP server and IP camera connect through network


• Instant playback in the current priview window


• Control PTZ in the current priview window use mouse or keyboard

Recording & Storage:

• Adopts the most advanced H.264 compression technology


• Every channel can setup the recording mode, such as: consecutive recording, motion recording, sensor recording etc. and can setup recording by scheme


• Supports not only variable bit rate but also variable frame rate


• The quality and continuity of every image when recording can be adjusted freely


• It supports multi-hard disk circular recording, so one need not change disk by hand

PlayBack:

• Playback and record can run at the same time and there without mutual effect


• System can playback in single partition or multi-partition


• System can set precisely any hour, any minute and second to quickly index record data


• System has several playing back paces: play back normally, single frame, quickly (2-5 time), slowly (1/2-1/5), freezing images and skipping to the set time


• System support to playback part zoom realtimely


• Support smart search

Control Function:

• Control PTZ or speed demo through RS485


• Control PTZ or speed demo use PC keyboard


• Set preset position for each camera independently


• Tour all preset position

Alarm Function:

• Support 32 channels sensor input and 32 channels alarm output


• Sound warning when alarming for each camera


• Digital map popup when there have alarm


• It has the long-distance transmission function of alarm signals through network


• Send Email automatically when camera or sensor alarming



Network Function:

• Support PSTNISDNADSLDDNLANInternet etc


• Support Dynamic IP


• It adopts advanced network compression technology


• Support remotely connection of NVR,IE,PDA,NVMP through network

Authority management and system protection :

• Locks keyboard and mouse preventing unauthorized access to the system


• Locks keyboard and mouse preventing unauthorized access to the system
