Specifications
1.Thickness:0.3mm-350mm2.Width:800mm-1300mm
3.thickness:0.3mm-350mm
4.Grade:5052 5083 5754
1. 5052 aluminum plate
Every effort has been made to ensure the reliability of the reported information, and is the result of a number of sources, including vendors and reference materials. Any use of the presented information is the user’s responsibility and is intended for educational purposes only.
Chemistry Data For 5052 Aluminuma
Silicon (Si) |
Iron (Fe) |
Copper (Cu) |
Manganese (Mn) |
Magnesium (Mg) |
Chromium (Cr) |
Zinc (Zn) |
Titanium (Ti) |
0.25 |
0.40 |
0.1 |
0.10 |
2.2-2.8 |
0.15-0.35 |
0.10 |
- |
(a) Aluminum constitutes the remainder. Amounts indicated are percentage maximums or ranges, unless indicated.
Mechanical Data for 5052 Aluminum
Aluminum Type / Temper |
Minimum Tensile Strength (ksi) |
Minimum Yield Strength (0.2%, ksi) |
5052 Aluminum Alloyb |
|
|
-O |
28 |
13 |
-H32 |
33 |
28 |
-H34 |
38 |
31 |
|
|
|
5052 Aluminum Sheet and Platec |
|
|
-O |
25 |
9.5 |
-H32 |
31 |
23 |
-H34 |
34 |
26 |
(b) Contains typical data for all shapes, and does not represent data for any specific shape.
(c) Data presented is the range for all sizes in the given shape and temper.
2. Other type 5000 series alloy aluminum plate
5000 Series Aluminium plate
This series aluminum sheet provided by Zhaoyang includes 5005, 5052, 5754, 5083 series, etc. The 5052, 5005, 5083 and 5A05 series are representative series.
5000 Aluminum plate Features
1.The main ingredient of this series aluminum sheet is magnesium element and the content is between 3% and 5%. It is also called aluminum magnesium alloy.
2.With its low density, it features high tensile strength and elongation.
3.This series aluminum sheet is a commonly used and mature series in China.
5000 Aluminum plate Applications
With the same area of other series, the weight of this aluminum sheet is lighter. As a result, it is used in aviation, such as in the fuel tanks in airplanes.
It is widely used in conventional industries.
This aluminum sheet can be used in continuously casting and rolling. It can be hot rolled. As a result, it can be used in oxidation and deep processing.
Other 5000 serier Aluminum Sheet Chemical Composition
Type |
Si |
Fe |
Cu |
Mn |
Mg |
Cr |
Zn |
Ti |
Impurity |
Alu |
|
Elements | |||||||||||
Each |
Amount |
||||||||||
5000seriers |
0.4 |
0.35 |
0.1 |
0.4-1.0 |
4.0-4.9 |
0.05-0.25 |
0.25 |
0.15 |
0.05 |
0.15 |
rest |
5005 |
0.3 |
0.7 |
0.2 |
0.2 |
0.50~1.1 |
0.1 |
0.25 |
— |
0.05 |
0.15 |
rest |
5050 |
0.4 |
0.7 |
0.2 |
0.1 |
1.1~1.8 |
0.1 |
0.25 |
— |
0.05 |
0.15 |
rest |
5083 |
0.4 |
0.4 |
0.1 |
0.40~1.0 |
4.0~4.9 |
0.05~0.25 |
0.25 |
0.15 |
0.05 |
0.15 |
rest |
5183 |
0.4 |
0.4 |
0.01 |
0.50~1.0 |
4.3~5.2 |
0.05~0.25 |
0.25 |
0.15 |
0.05 |
0.15 |
rest |
5086 |
0.4 |
0.5 |
0.1 |
0.20~0.7 |
3.5~4.5 |
0.05~0.25 |
0.25 |
0.15 |
0.05 |
0.15 |
rest |
