Specifications
4ch Hardware Video Capture Card with s/w and SDKH.264, 4chs video&audio, TI TMS320DM645
D1,Real Time
2ch D1 realtime
4ch Hardware Video Capture Card with s/w and SDK
VEC FB Series video and audio compression card use Texas Instrument's high-performance DSP DM645 with hardware H.264 algorithm compression that reproduces excellent image quality and achieves high compression ratio for the best possible performance. This series card can provide 4/8/16 channels 2CIF/HD1/CIF/QCIF with 25/30fps and dual-stream encoding; it also can support full channels 4CIF(D1) with 12/15fps or half channels 4CIF(D1) with 25/30fps encoding.
Features
>H.264 hardware compression algorithm for high compression ratio and excellent image quality. >4/8/16 channels 2CIF/HD1/CIF/QCIF or half channels 4CIF(D1) real-time recoding and dual-stream supported, also support full channels 4CIF(D1) non-real time recoding.
>4/8/16 channels 4CIF(D1)/CIF/QCIF RAW video stream output.
>Support 4CIF(D1)/CIF/QCIF real-time preview for up to 64 cameras.
>Video detection supports Motion detection, Video loss and Video block.
>Support OSD/LOGO overlay, Privacy masking, Frame rate and Bit rate dynamically adjusted etc.
>Provide full SDK with Windows and Linux operation system.
>Compatible with full range of Dahua’s Compression card.
Specification:
Model |
VEC1604FB |
VEC0804FB |
VEC0404FB |
General | |||
Encoding Chip |
TMS320DM645 |
||
PCI Standard |
PCI 2.2 |
||
Video | |||
Input |
16 channel, BNC(1.0Vp-p, 75?) |
8 channel, BNC(1.0Vp-p, 75?) |
4 channel, BNC(1.0Vp-p, 75?) |
Standard |
NTSC(525Line, 60f/s), PAL(625Line, 50f/s) |
||
Preview Resolution |
4CIF(D1)/CIF/QCIF, Realtime |
||
Compression |
H.264 |
||
Encoding Resolution |
NTSC: 704×480(4CIF/D1), 704×240(2CIF), 352×480(HD1), 352×240(CIF), 176×120(QCIF) PAL: 704×576(4CIF/D1), 704×288(2CIF),352×576(HD1), 352×288(CIF), 176×144(QCIF) |
||
Encoding Speed |
Main Stream: Full-channels 2CIF/HD1/CIF/QCIF or Half-channels 4CIF(D1) with 25/30fps; Full-channels 4CIF(D1) with 12/15fps |
||
Extra Stream: CIF/QCIF with 25/30 fps | |||
Bit Rate |
32Kbps~4Mbps |
||
RAW Stream |
Full-channels 4CIF(D1)/CIF/QCIF |
||
Audio | |||
Input |
16 channel, BNC(200-2800mV, 30KΩ) |
8 channel, BNC(200-2800mV, 30KΩ) |
4 channel, BNC(200-2800mV, 30KΩ) |
Compression |
PCM/ADPCM |
||
Sampling Rate |
8bit/8KHz, 16bit/8KHz |
||
Bit Rate |
32Kbps |
||
System Requirement | |||
Operating System |
Windows 2000/XP/2003/Vista/7, Linux |
||
CPU |
Intel or AMD |
||
Motherboard |
Based on Intel or AMD chipset, PCI 2.2 slot |
||
Memory |
256MB or above |
||
Graphics |
NVIDIA, AMD-ATI, Intel graphics cards, memory 64MB or above |
||
Environmental | |||
Working Environment |
-10~+55C / 10~90%RH / 86~106kpa |
||
Power Requirement |
5V±10%, 3.3V±10% |
||
Power Consumption |
11W |
7W |
3W |
Dimension |
257mm×106.6mm |
182.5mm×106.6mm |
152.5mm×93.2mm |
