Hikvision 16 Channel PCI-E Hardware Compression Card

Hikvision 16 Channel PCI-E Hardware Compression Card thumbnail-1
Hikvision 16 Channel PCI-E Hardware Compression Card photo-1
US$ 1 - 500 MOQ: 2 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
KingCCTV
Model Number:
DS-4216HF-E (PCI-E)
Contact Supplier Request Quote Chat Now
Shenzhen KingCCTV Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name KingCCTV
Model Number DS-4216HF-E (PCI-E)

16 Channel PCI-E Hardware Compression Card

DS-4216HF-E (PCI-E)

Hikvision 16 Channel PCI-E Hardware Compression Card



Available Models

Cards are stackable to obtain 64 channels maximum
DS-4016HCI
16 channels video and audio CIF (real time)
or 8 channels video and audio 4CIF (real time)
or 16 channel DCIF (real time)
or 16 channel 4CIF(not real time)

Features & Functions

  1. Real-time video and audio compression, no frame lost
  2. 4CIF preview resolution
  3. Comply with PCI 2.2 standard, a PC can support up to 64 channels
  4. Support WINDOWS 2000/XP operating system
  5. Setable video quality and bitrate
  6. Setable brightness, contrast, saturation and hue of video signal
  7. Support motion detection
  8. Support OSD, LOGO and MASK overlay
  9. Support watermark technology
  10. Support double encoding





Specifications

Item Description
Video Format PAL and NTSC
Video Input 16 Ch BNC (1.0Vp-p, 75ohm)
Audio Input 16 Ch BNC (2.0Vp-p, 1Kohm)
Preview Resolution Resolution: 704*576(PAL),704*480(NTSC)
Video Compression H.264, Support CBR, VBR; Frame: 25F/s(PAL),30F/s(NTSC); Output: 32kbps-1000kbps(CIF) or 70kbps-4000kbps(4CIF)
Compression Resolution 4CIF:704*576(PAL),704*480(NTSC); CIF:528*384(PAL),528*320(NTSC); 2CIF:704*288(PAL),704*240(NTSC); CIF:352*288(PAL),352*240(NTSC); QCIF:176*144(PAL), 176*120(NTSC)
Audio Compression OggVorbis, Sample ratio is 16KHz, Output ratio is 16kbps
Power Consumption Less than 7W
Working Temperature -10°C ~ +50°C
Working Humidity 10%~90%
Dimension 185 * 107mm
Computer Configuration (Recommend) Mainboard: Intel 945 or 965 Chipset; Memory: 512MB; Display Adapter: Geforce Mx400/420/440 series or ATI Radeon 7000/7200/7500/8500/9000 X550series
