Specifications
h 264 network dvr software video dvr HK-S4008F1.TV out,HDMI,VGA,BNC
2.fps200fps(P)/240fps(N)
3.720P high definition
cctv dvr player cctv net video dvr cctv digital video recorder HK-S4008F with HDMI
Application
H.264 compression, Can Display up to 16 Cameras, Support 16 channel playback simultaneously
Recommended installation areas are Securities Companies, Change Booths, Pawnshops, Jewerlers, Galleries, Exhibition Halls, Department Stores, Convenience Stores, Discount Offices, Hospitals, Police Stations, Subway Stations, Airports, Banks etc.
Features
(1) H.264 compression algorithm ideal for standalone DVR
(2) Realtime live display up to 16 cameras with 720P high definition, 400/480 fps recording for CIF & special channel D1(4CIF) realtime recording
(3) 2U standalone DVR with high performance, widely accepted in the worldwide security industry
(4) 16 channel playback simultaneously
(5) Dual encoding streams flexible for network transmission and mobile phone monitoring
(6) Pentaplex function: live, recording, playback, backup & remote access
(7) 4 HDDs supported, eSATA port & CD-RW/DVD-RW supported
(8) Multiple control methods: front panel, IR remote controller, keyboard, USB mouse and network keyboard
(9) Smart video detection: motion detection, camera blank, video loss
(10) Smart camera settings: privacy masking, camera lock, color setting and title display
(11) Pan Tilt Zoom and Speed Dome Control: more than 60 protocols supported, preset, scan, auto pan, auto tour, pattern, auxiliary function supported.
(12) Easy backup methods: USB devices, CD-RW/DVD-RW & network download
(13) Alarm triggering screen tips, buzzer, PTZ preset, matrix output, e-mail, FTP upload
(14)Smart HDDs Management: non-working HDD hibernation, HDD faulty alarm, Raid function
(15) Powerful network software: built-in web server, multi-DVR client, MSS(mobile phone surveillance software ) & CMS
(16) Video matrix and loop function
Specifications:
Model/Item |
HK-S4008F h 264 network dvr software |
| Compression Format | H.264 / G.711 |
| Operating system | Embedded LINUX |
| Main Processor | High performance embedded microprocessor |
| User Interface | GUI, on-screen menu tips. |
| Control Mode | Front panel, USB mouse, IR remote control, Keyboard, Network |
| System Resources | Pentaplex function: live, recording, playback, backup & remote access |
| System Status | HDD status, data stream statistics, log record, bios version, on-line user etc. |
| Video Input | BNC x 4,1.0VP-P,75Ω |
| Video looping | 8 channels |
| Video Output | 1 TV, 1 Spot, BNC(1.0Vp-p, 75Ω), 1 VGA, 1 HDMI |
| Video Standards | PAL(625Line,50f/s),NTSC(525Line,60f/s) |
| Video Privacy Masking | 4 self-defined four-sided zones for privacy masking for each camera |
| Video Resolution | D1/4CIF(704*576/704*480) CIF(352*288/352*240) / QCIF(176*144/176*120) |
| Main Stream Record Speed | Channel 1: D1/CIF/QCIF (1~25/30fps); Channel 2~4: CIF/QCIF (1~25/30fps), D1 (1~6fps) |
| Extra Stream Speed | QCIF(1~25/30fps) |
| Video Bit Rate | 32~2048Kb/s |
| Video Tour Display | Support |
| Video Image Quality | 1~6 level(level 6 is the best, VBR effectively) |
| Recording Priority | Manual >Alarm >MD >Regular |
| Recording Mode | Manual, Schedule(Regular(Continuous), MD(Video detection: Motion detection, Camera blank, Video loss), Alarm), Stop |
| Recording Priority | Manual >Alarm >MD >Regular |
| Recording Interval | 1~120 min. (default: 60 min.), Pre-record: 1~30 sec., Post-record: 10~300 sec. |
| OSD | Camera title, time, video loss, camera lock, motion detection, recording |
| Display Resolution | 1280*1024, 1280*720, 1024*768, 800*600 |
| Audio Input | 200-2800mV, BNC x 4 |
| Audio Output | 1 channel, BNC(200-3000mV, 5KΩ) |
| Audio Bidirectional Talk | 1 channel Input, BNC(200-2800mV, 30KΩ), 1 channel Output, BNC(200-3000mV, 5KΩ) |
| Motion Detection | Zones: 396(22*18), Sensitivity: 1~6 (level 6 is highest) |
| Video Loss & Camera Blank | Support |
| Alarm Input | 4 channels |
| Relay output | 6 channel, 30VDC, 1A, NO/NC, form-C |
| Hard Disk | 4 SATA ports, 4 HDDs or 3 HDDs + 1 CD/DVD-RW, Max 2TB per HDD supported |
| Playback | 1/2/4/All |
| Dimension | 2U, 440mmx460mmx89mm (W*D*H) |
| Weight | Gross weight:8kg ; Net weight:6.5kg |
Connections:
