Help Center24/ 32CH H.264 Network DVR hd Dvr Manual
Related Products
-
4/ 8CH D1/ 960H AHD DVR/ Digital Video Recorder/ H 264 NVR/ P2P/ Cloud/ 1HDD/ CCTV DVR/ hd Dvr ManualUS$ 53 - 167MOQ: 1 Piece -
16 Channels Factory Direct Low Cost CCTV H.264 Standalone DVR , Cms Free Software, Mobile Dvr sdUS$ 53 - 167MOQ: 1 Piece
-
Factory Direct Low Cost CCTV H.264 Standalone DVR , Cms Free Software, Cctv DvrUS$ 53 - 167MOQ: 1 Piece
-
Factory Direct Low Cost CCTV H.264 Standalone DVR , Cms Free Software, Dvr h 264US$ 53 - 167MOQ: 1 Piece
-
AHD LCD Dvr Camera Free Client Software H.264 Alhua DvrNegotiableMOQ: 1 Set
W What is the Specifications of our products?
| Model No. | HK-S3324F | HK-S3332F |
| Compression Format | H.264 Standard compression | |
| Operation System | Embedded LINUX | |
| Main Processor | High-performance embedded microcontroller Hi 3521 | |
| Control Mode | Front panel, USB mouse, IR remote control, Keyboard, Network | |
| System Resources | Pentaplex function: live, recording, playback, backup & remote access | |
| Video Input | BNC x 24, 1.0VP-P,75O | BNC x 32, 1.0VP-P,75O |
| Video Output | 1CH BNC TV-OUT, 1HDMI; Support VGA and BNC simultaneous output | |
| Main Stream Record Speed | CIF 320x240 600FPS@PAL; CIF 352x240 720FPS@NTSC | CIF 320x240 800FPS@PAL; CIF 352x240 960FPS@NTSC |
| Extra Stream Speed | QCIF(1~25/30fps) | |
| Recording Mode | Manual,timing,motion detection,video blind and video loss recording | |
| Audio Input/Output | 8CH RCA / 1CH RCA | |
| Hard Disk Storage | 2 or 4 SATA,Maximum 16TB or 1 SATA port with DVD RW | |
| Alarm Input/Output | 4ch/1ch input/output | |
| Multiplex Operation | Live display / record / playback / backup / network operations | |
| Playback mode | Multiple slow and rapid play speeds, manual and single-frame play modes,and support positioning the time by driving the sliding bar | |
| Backup Device | U-disk/Hard disk/USB CD/DVD-RW/Download | |
| Pre-alarm Recording | recording for 5 seconds before alarming | |
| Network Protocol | TCP/IP,UDP,DHCP,IP Filter,PPPOE,FTP,DNS,DDNS,NTP,UPNP,EMAIL,Alarm Server,ARSP | |
| Ethernet | 10/100 Base-T. Supports remote control and live view via Ethernet | |
| Web Interface | Internet Explorer (5 users access simultaneously); Operating System: Windows Vista / XP / 2000 | |
| VGA Interface | Built-in | |
| IR Remote Control | YES (IR receiver built-in) | |
| Mobile Phone Support | Symbian, Windows CE, iPhone, Google Android and BlackBerry | |
| Language | English, Chinese Simplified, Chinese Traditional, Italian, Spanish, Japanese, Russian, French, German, Portuguese, Turkish, Polish, Hungarian, Finnish, Persian, Thai, Greek, Vietnamese, Romanian, Brazilian, Swedish, Arabic, Bahasa Indonesia, Hebrew, Ukrainian | |
| PTZ Control | Yes | |
| USB Mouse | Yes | |
| Power Source | 12V/6A DC(±10%) | |
| Key Lock | Yes(Password Protection) | |
| System Recovery | System auto recovery after power failure | |
| Dimension | 2U,440*360*70mm(DVR Size); 500mm X 480mm X 170mm(Pack Size) | |
| Working Temperature | -10 ~ +55°C | |
| Working Humidity | 10%- 90% | |
| Weight | 6.3KG (No HDD) | 8.7KG (No HDD) |
Connections
Application
DVS real host,super-network functions,Support IE browser centralized monitoring and CMS Software for multiple DVR from diferent place (up to 64 DVR view per screen) simultaneously, per screen can monitoring and playback from multiple DVR images, thorough solve most of the DVR can only manage a single DVR,as well as monitoring and playback can not be a problem at the same time.
CMS software
Login
Two logging modes are provided: by IP address and by domain.
Control
COMMON: Reboot server, shutdown server, remote upgrade.
VIDEO: remotely adjust the video frequency, brightness, chromaticity, contrast and saturation degree to the best visual effect
LOG: The user can check the logs in the hard disk on the DVR
DOWNLOAD: remotely download files from the hard disk on the DVR,and save them locally for backup or play.
Setup
Common setup, coding setup, visual recording setup, alarm setting, cradle head setup, movement monitoring, video loss, and shielding alarm
PTZ Control
ZOOM, FOCUS, IRIS, PANT, TITL
Window browsing mode
switching: single windows, 4 windows, 6 windwos, 8 windows, 9 windows 16 windows,32 windows and 64 windows
Toolbar
Start, pause, Stop, Slow Play, Fast Play Single Frame, Screenshot, Video Recording, Playbak, Volume Control, Total time for file playing.
Software / User's Manual Download
KingCCTV HK-S2204F/S2108F Standalone DVR Manual(1,637KB)
Mobile Manual for KingCCTV HK-S2204F/S2108F Standalone DVR(957KB)
CMS Software for Standalone DVR HK-S2204F/S2108F(1,011KB)
