16CH Hybrid DVR hd dvr watch driver download
- 5000 Piece / Pieces per Month
- Shenzhen
- Credit Card
You May Like
Product Details
Place of Origin | Guangdong, China | Brand Name | KingCCTV | |
Model Number | HK-H5016F |
Product Description
W What is the Specifications of our products?
Model No. | HK-S4004FD | HK-S4008FD | HK-S4016FD |
Compression Format | H.264 / G.711 | ||
Operation System | Embedded LINUX | ||
User interface | GUI, on-screen menu tips. | ||
Main Processor | High-performance embedded microcontroller | ||
Control Mode | Front panel, USB mouse, IR remote control, Keyboard, Network | ||
System Resources | Pentaplex function: live, recording, playback, backup & remote access | ||
System status | HDD status, data stream statistics, log record, bios version, on-line user etc. | ||
Video Input | BNC x 4, 1.0VP-P,75O | BNC x 8, 1.0VP-P,75O | BNC x 16, 1.0VP-P,75O |
Video looping | 4ch | 8ch | 16ch |
Video Output | 1 TV, 1 Spot, BNC(1.0Vp-p, 75Ω), 1 VGA, 1 HDMI | ||
Video Standards | PAL(625Line,50f/s),NTSC(525Line,60f/s) | ||
Video Privacy Masking | 4 self-defined four-sided zones for privacy masking for each camera | ||
Video Resolution | D1/4CIF(704*576/704*480); CIF(352*288/352*240) / QCIF(176*144/176*120) | ||
Main Stream Record Speed | Channel 1: D1/CIF/QCIF (1~25/30fps); Channel 2~4: CIF/QCIF (1~25/30fps), D1 (1~6fps) | Channel 1: D1/CIF/QCIF (1~25/30fps); Channel 2~8: CIF/QCIF (1~25/30fps), D1 (1~6fps) | Channel 1 & 9: D1/CIF/QCIF (1~25/30fps); Others Channel: CIF/QCIF (1~25/30fps), D1 (1~6fps) |
Extra Stream Speed | QCIF(1~25/30fps) | ||
Video Bit Rate | 32~2048Kb/s | ||
Video Tour Display | Support | ||
Video Image Quality | 1~6 level(level 6 is the best, VBR effectively) | ||
Recording Mode | Manual, Schedule(Regular(Continuous), MD(Video detection: Motion detection, Camera blank, Video loss), Alarm), Stop | ||
Recording Priority | Manual >Alarm >MD >Regular | ||
Recording Interval | 1~120 min. (default: 60 min.), Pre-record: 1~30 sec., Post-record: 10~300 sec. | ||
OSD | Camera title, time, video loss, camera lock, motion detection, recording | ||
Display Resolution | 1280*1024, 1280*720, 1024*768, 800*600 | ||
Audio Input | 200-2800mV, BNC x 4 | 200-2800mV, BNC x 8 | 200-2800mV, BNC x 16 |
Audio Output | 1 channel, BNC(200-3000mV, 5KΩ) | ||
Audio Compression | G.711 | ||
Audio Bidirectional Talk | 1 channel Input, BNC(200-2800mV, 30KΩ), 1 channel Output, BNC(200-3000mV, 5KΩ) | ||
Motion Detection | Zones: 396(22*18), Sensitivity: 1~6 (level 6 is highest) | ||
Video Loss & Camera Blank | Support | ||
Alarm Input | 4 channels | 8 channels | 16 channels |
Relay output | 6 channel, 30VDC, 1A, NO/NC, form-C | ||
Hard Disk | 4 SATA ports, 4 HDDs or 3 HDDs + 1 CD/DVD-RW, Max 2TB per HDD supported | ||
Space Occupation | Audio: 28.8MB/H, Video: 56~500MB/H | ||
HDD Management | Hard disk hibernation technology, HDD faulty alarm & Raid (Redundancy) | ||
Recording Mode | Manual, continuous, video detection(including motion detection, camera blank, video loss), Alarm | ||
Overwrite Mode | Support | ||
Search Mode | Time/Date, Alarm, Motion Detection & exact search ( accurate to second) | ||
Playback | 1/2/4/All | ||
Playback Functions | Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom(any size) | ||
Backup Mode | Flash drive/ USB HDD/ USB CD/DVD-RW/ eSATA Device / Built-in SATA burner/ Network download | ||
Network nterface | RJ-45 Port (10/100M) | ||
Network Functions | TCP/IP, UDP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Email, Alarm Server | ||
Network Remote operation | Monitor, PTZ control, Playback, System setting, File download, Log information | ||
USB Interface | 2 ports, 1 for mouse control, 1 for backup | ||
RS232 | keyboard, PC communication | ||
RS485 | PTZ control | ||
eSATA | 1 port | ||
Power Supply | AC 100~240 V, 50/60 Hz | ||
Power consumption | 25W | 30W | 40W |
Working Temperature | -10~+55 degree | ||
Working Humidity | 10%- 90% | ||
Atmosphere Pressure | 86kpa - 106kpa | ||
Dimension | 2U, 440mmx460mmx89mm (W*D*H) | ||
Mounting | Desktop or rack | ||
Weight | Gross weight:8kg; Net weight:6.5kg |
Connections
Application
DVS real host,super-network functions,Support IE browser centralized monitoring and CMS Software for multiple DVR from diferent place (up to 64 DVR view per screen) simultaneously, per screen can monitoring and playback from multiple DVR images, thorough solve most of the DVR can only manage a single DVR,as well as monitoring and playback can not be a problem at the same time.
CMS software
Login
Two logging modes are provided: by IP address and by domain.
Control
COMMON: Reboot server, shutdown server, remote upgrade.
VIDEO: remotely adjust the video frequency, brightness, chromaticity, contrast and saturation degree to the best visual effect
LOG: The user can check the logs in the hard disk on the DVR
DOWNLOAD: remotely download files from the hard disk on the DVR,and save them locally for backup or play.
Setup
Common setup, coding setup, visual recording setup, alarm setting, cradle head setup, movement monitoring, video loss, and shielding alarm
PTZ Control
ZOOM, FOCUS, IRIS, PANT, TITL
Window browsing mode
switching: single windows, 4 windows, 6 windwos, 8 windows, 9 windows 16 windows,32 windows and 64 windows
Toolbar
Start, pause, Stop, Slow Play, Fast Play Single Frame, Screenshot, Video Recording, Playbak, Volume Control, Total time for file playing.
Software / User's Manual Download
KingCCTV HK-S2204F/S2108F Standalone DVR Manual(1,637KB)
Mobile Manual for KingCCTV HK-S2204F/S2108F Standalone DVR(957KB)
CMS Software for Standalone DVR HK-S2204F/S2108F(1,011KB)
W What is the Applications of our products?
P Packaging &Shipping,Trade Terms
W Why choosing us?
1. More professional, better quality.
We engaged in software & hardware development, manufacturing and sales for security & safe products.( CCTV camera, IP camera, DVR, NVR ) for about 10 years.
2. OEM/ ODM service available.
Any your idea on camera we can help you to design and put in solution.
3.Strong Tech support.
* Presale: product consultation and solution design can be provided.
* After sale: We offer a 2-years warranty, which includes maintenance and technical support for all the products. Within the warranty period, exchanges and free maintenance are provided. If any quality issues occur, please contact us for technical support via telephone, email, or any method available on our site.
* We can also provide customized products, project designs, our project partner like: Shell in Japan, Barranquilla Harbour in Colombia, Greece National Park..
3. Strict Quality Control :
All of our electronic parts will stay in constant temperature machines more than 48 hours before assembly, all products wiil be fully inspected before shipment.
with CE, ROHS, FCC approval.
A ABOUT US
O Our Certifications
O Our Exhibitions & Customers visiting
F FEEDBACK
C Customers from All over the World
F FAQ
Q1. Can I get samples?
A1. Sure. We will appreciate it if you’d like to purchase samples for tests first. For sample order, there is no limit on MOQ. And we will send samples as soon as possible after confirming your payment.
Q2. Are you factory?
A2. Yes we are. We have our own factory, which can help you get factory direct selling products with competitive prices. We always monitor strictly the quality of products before they leave factory.
Q3. How about warranty period? If any problem, can I get enough support?
A3. All the products you purchase from us have 2 YEAR WARRANTY. If the product is broken during this time, you can ship the item to us to repair or you can keep it and we will send a total new one to you soon. With strong technical team, we can provide life-time and timely technical support whenever there is something wrong with our products.
Q4. Why the shipping cost is so much? How about delivery time?
A4. Before shipment, we will find the most reliable carrier for you to make sure of lowest freight cost and shortest lead time. As for the delivery time, it depends on the order quantity. Normally it would take 3-15 days for one order.
Q5. Can I become your sole distributor in my place?
A6. We appreciate that. And we will discuss about your market situation together and after confirmation we will send you a contract with detailed requirements about sales targets.
Q6. Can you give us enough brochures and ideas as promotion to our customers?
A6. Yes, we’d love to help you promote your business. Welcome to share your idea of your market status and we will give you valuable advice and detailed information you need.
Q7. Can you make OEM products for us?
Q8. Sure we can. Do not worry, we can print your logo both on the products and boxes. But we might ask for MOQ according to the real situation.
H How to Contact us?
Contact Us
- Shenzhen KingCCTV Technology Co., Ltd.
- Contact nameKingwood Liu Chat Now
- Phone86-755-86165030-801
- Address26E, Block 2, Nanguo Bldg., No. 2065, Hongling Middle Rd., Futian District, Shenzhen, Guangdong
