New Pull I5-3317U Mobile Cpu SR0N8 AV8063801058002 Ivy Bridge Bga Core i5 Processor

New Pull I5-3317U Mobile Cpu SR0N8 AV8063801058002 Ivy Bridge Bga Core i5 Processor thumbnail-1
New Pull I5-3317U Mobile Cpu SR0N8 AV8063801058002 Ivy Bridge Bga Core i5 Processor photo-1
US$ 135 - 140 MOQ: 1 Piece
Key Specifications
Get Latest Price
Products Status:
Stock
Application:
Laptop
Processor Brand:
Intel
Contact Supplier Request Quote Chat Now
Shenzhen Shines Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
HK
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Products Status Stock
Application Laptop
Processor Brand Intel
Type Dual-Core
Processor Type Intel Core
L2 Cache 3MB
Socket Type Other, LGA1023
Main Frequency 1.7GHz
Brand Name Intel
Model Number SR0N8
Place of Origin Guangdong, China

New pull i5-3317U Mobile cpu SR0N8 AV8063801058002 Ivy Bridge bga core i5 processor

Intel Core i5-3317U specifications

General information
Type CPU / Microprocessor
Market segment Mobile
Family

Intel Core i5 Mobile
Model number  ?

i5-3317U
CPU part number

  • AV8063801058002 is an OEM/tray microprocessor
Frequency  ?  1700 MHz
Turbo frequency 2600 MHz (1 core)
2400 MHz (2 cores)
Bus speed  ?  5 GT/s DMI
Clock multiplier  ?  17
Package 1023-ball micro-BGA (BGA1023)
Socket BGA1023
Size 1.22" x 0.94" / 3.1cm x 2.4cm
Introduction date June 3, 2012
Price at introduction $225
S-spec numbers
  Production processors
Part number SR0N8
AV8063801058002 +
Architecture / Microarchitecture
Microarchitecture Ivy Bridge
Processor core  ?  Ivy Bridge
Core stepping  ?  L1 (SR0N8)
CPUID 306A9 (SR0N8)
Manufacturing process 0.022 micron
Data width 64 bit
The number of cores 2
The number of threads 4
Floating Point Unit Integrated
Level 1 cache size  ?  2 x 32 KB 8-way set associative instruction caches
2 x 32 KB 8-way set associative data caches
Level 2 cache size  ?  2 x 256 KB 8-way set associative caches
Level 3 cache size 3 MB 12-way set associative shared cache
Physical memory 32 GB
Multiprocessing Not supported
Features
  • MMX instructions
  • SSE / Streaming SIMD Extensions
  • SSE2 / Streaming SIMD Extensions 2
  • SSE3 / Streaming SIMD Extensions 3
  • SSSE3 / Supplemental Streaming SIMD Extensions 3
  • SSE4 / SSE4.1 + SSE4.2 / Streaming SIMD Extensions 4 ?
  • AES / Advanced Encryption Standard instructions
  • AVX / Advanced Vector Extensions
  • F16C / 16-bit Floating-Point conversion instructions
  • EM64T / Extended Memory 64 technology / Intel 64  ?
  • NX / XD / Execute disable bit  ?
  • HT / Hyper-Threading technology  ?
  • TBT 2.0 / Turbo Boost technology 2.0  ?
  • VT-x / Virtualization technology  ?
  • VT-d / Virtualization for directed I/O
Low power features Enhanced SpeedStep technology  ?
Integrated peripherals / components
Integrated graphics GPU Type: HD 4000
Base frequency (MHz): 350
Maximum frequency (MHz): 1050
The number of supported displays: 3
Memory controller The number of controllers: 1
Memory channels: 2
Supported memory: DDR3-1333, DDR3-1600, DDR3L-1333, DDR3L-1600, DDR3L-RS 1333, DDR3L-RS 1600
Maximum memory bandwidth (GB/s): 25.6
Other peripherals
  • Direct Media Interface 2.0
  • PCI Express 2.0 interface
Electrical / Thermal parameters
Maximum operating temperature  ?  105°C
Thermal Design Power  ?  17 Watt
 CPU ID information for the Core i5-3317U

Our CPUID database contains 3 records for this microprocessor. See all submitted records.

Use our CPU identification tool to check features of your processor.

NOTE: The CPU ID information below was taken from one chip and may include features that are not present in all different steppings of the Intel Core i5 Mobile i5-3317U microprocessor.



Manufacturer: Intel Measured frequency: 1696 MHz
CPU Family: Core i5 Mobile Comment: CPU of SAMSUNG ATIV SMART PC XE700T1C-A01CL (tablet with keyboard)
Processor Number: i5-3317U
Part number (supplied): AV8063801058002 Submitted by: Daniel Dinamarca Tosso
Part number (guessed):
AV8063801058002
 Submitted on:
S-Spec Number:   CWID version: 0.5
General information
Vendor: GenuineIntel
Processor name (BIOS): Intel(R) Core(TM) i5-3317U CPU @ 1.70GHz
Cores: 2
Logical processors: 4
Processor type: Original OEM Processor
CPUID signature: 306A9
Family: 6 (06h)
Model: 58 (03Ah)
Stepping: 9 (09h)
TLB/Cache details: 64-byte Prefetching
Data TLB0: 2-MB or 4-MB pages, 4-way set associative, 32 entries
Data TLB: 4-KB Pages, 4-way set associative, 64 entries
Instruction TLB: 4-KB pages, 4-way set associative, 64 entries
L2 TLB: 1-MB, 4-way set associative, 64-byte line size
Shared 2nd-level TLB: 4 KB pages, 4-way set associative, 512 entries
Cache: L1 data L1 instruction L2 L3
Size: 2 x 32 KB 2 x 32 KB 2 x 256 KB 3 MB
Associativity: 8-way set
associative		 8-way set
associative		 8-way set
associative		 12-way set
associative
Line size: 64 bytes 64 bytes 64 bytes 64 bytes
Comments: Direct-mapped Direct-mapped Non-inclusive
Direct-mapped		 Inclusive
Shared between all cores

Instruction set extensions Additional instructions
MMX CLFLUSH
SSE CMOV
SSE2 CMPXCHG16B
SSE3 CMPXCHG8B
SSSE3 Enhanced REP MOVSB/STOSB
SSE4.1 FXSAVE/FXRSTORE
SSE4.2 MONITOR/MWAIT
AES PCLMULDQ
AVX POPCNT
F16C RD/WR FSGSBASE instructions
  RDRAND
  RDTSCP
  SYSENTER/SYSEXIT
  XSAVE/XRESTORE states
  XSETBV/XGETBV are enabled

Major features Other features
On-chip Floating Point Unit 36-bit page-size extensions
64-bit / Intel 64 64-bit debug store
NX bit/XD-bit Advanced programmable interrupt controller
Hyper-Threading Technology CPL qualified debug store
Intel Virtualization Clock modulation duty cycle extension
Turbo Boost Debug store
Enhanced SpeedStep Debugging extensions
  Digital Thermal Sensor capability
  Extended xAPIC support
  LAHF/SAHF support in 64-bit mode
  Machine check architecture
  Machine check exception
  Memory-type range registers
  Model-specific registers
  Package thermal management
  Page attribute table
  Page global extension
  Page-size extensions (4MB pages)
  Pending break enable
  Perfmon and Debug capability
  Physical address extensions
  Power Limit Notification capability
  Process context identifiers
  Self-snoop
  Supervisor Mode Execution Protection
  TSC rate is ensured to be invariant across all states
  Thermal monitor
  Thermal monitor 2
  Thermal monitor and software controlled clock facilities
  Time stamp counter
  Timestamp counter deadline
  Virtual 8086-mode enhancements
  xTPR Update Control

CPUs, related to Intel Core i5-3317UThe list of related CPUs does not include all models. For the complete list, please see the related "Ivy Bridge" processors for socket BGA1023 page.

Model Cores /
Threads		 Frequency Turbo
frequency		 L3
cache		 TDP Features
Intel Core i5 Mobile family, BGA1023
   Core i5-3317U 2 / 4 1.7 GHz 2.6 GHz 3 MB 17W AES, AVX, HT, TBT
   Core i5-3437U 2 / 4 1.9 GHz 2.9 GHz 3 MB 17W AES, AVX, HT, TXT, TBT >
   Core i5-2410M (BGA) 2 / 4 2.3 GHz 2.9 GHz 3 MB 35W AES, AVX, HT, TBT >
   Core i5-2415M 2 / 4 2.3 GHz 2.9 GHz 3 MB 35W AES, AVX, HT, TBT >
   Core i5-2435M 2 / 4 2.4 GHz 3 GHz 3 MB 35W AES, AVX, HT, TBT >
   Core i5-2450M (BGA) 2 / 4 2.5 GHz 3.1 GHz 3 MB 35W AES, AVX, HT, TBT >
   Core i5-3210M (BGA) 2 / 4 2.5 GHz 3.1 GHz 3 MB 35W AES, AVX, HT, TBT >
   Core i5-2520M (BGA) 2 / 4 2.5 GHz 3.2 GHz 3 MB 35W AES, AVX, HT, TXT, TBT >
   Core i5-3230M (BGA) 2 / 4 2.6 GHz 3.2 GHz 3 MB 35W AES, AVX, HT, TBT >
   Core i5-2540M (BGA) 2 / 4 2.6 GHz 3.3 GHz 3 MB 35W AES, AVX, HT, TXT, TBT >
   Core i5-3320M (BGA) 2 / 4 2.6 GHz 3.3 GHz 3 MB 35W AES, AVX, HT, TXT, TBT >
   Core i5-3340M (BGA) 2 / 4 2.7 GHz 3.4 GHz 3 MB 35W AES, AVX, HT, TXT, TBT >
   Core i5-3360M (BGA) 2 / 4 2.8 GHz 3.5 GHz 3 MB 35W AES, AVX, HT, TXT, TBT >
   Core i5-3365M 2 / 4 2.8 GHz 3.5 GHz 3 MB 35W AES, AVX, HT, TXT, TBT >
   Core i5-3380M (BGA) 2 / 4 2.9 GHz 3.6 GHz 3 MB 35W AES, AVX, HT, TXT, TBT >
Intel Core i5 Mobile family, Ivy Bridge micro-architecture, Other sockets
   Core i5-3340M (PGA) 2 / 4 2.7 GHz 3.4 GHz 3 MB 35W AES, AVX, HT, TXT, TBT >
   Core i5-3360M (PGA) 2 / 4 2.8 GHz 3.5 GHz 3 MB 35W AES, AVX, HT, TXT, TBT >
   Core i5-3380M (PGA) 2 / 4 2.9 GHz 3.6 GHz 3 MB 35W AES, AVX, HT, TXT, TBT >
Other families, Ivy Bridge micro-architecture, BGA1023
   Celeron 1017U 2 / 2 1.6 GHz   2 MB 17W AES, AVX, HT, TBT >
   Celeron 1037U 2 / 2 1.8 GHz   2 MB 17W AES, AVX, HT, TBT >
   Pentium 2117U 2 / 2 1.8 GHz   2 MB 17W AES, AVX, HT, TBT >
   Pentium 2127U 2 / 2 1.9 GHz   2 MB 17W AES, AVX, HT, TBT >
   Core i3-3130M (BGA) 2 / 4 2.6 GHz   3 MB 35W AES, AVX, HT, TBT >
   Core i7-3540M (BGA) 2 / 4 3 GHz 3.7 GHz 4 MB 35W AES, AVX, HT, TXT, TBT >
