(CJB30K) Scale Measuring Weight Checking Machine

Specifications

Weight Checking Machine
1.Germany HBM digital load cell
2.Customized machine is available
3.All stainless steel made

Company Information --Weight Checking Machine



1- Anhui Yuanhong Machinery Automation Co.,Ltd is a high and new technology enterprise

    which specialized in R&D and manufacture automatic packaging machine since 1995.

2- Specialized in 1kg-50kg powder & granule automatic bag packaging machine, secondary

    packaging machine (small bags into big bag), bags/battles into box line Robot Palletizer,

    automatic packing and packaging line, bag-sewing machine.



                                      WELCOME TO VISIT OUR COMPANY !!!





Application -- Weight Checking Machine



The machine suits to inspect large packing line for terminal process, controlled by many load

sensors and touch screen, also can store more than 10 kinds of different specifications to meet

different need, when unqualified products occur alarm lamp and stop conveying, easy to operate.







Specifications -- Weight Checking Machine

MODEL		CJB30K
Testing Weight		2-30kg
Resolution		±5g - ±10g
Sorting Speed		10 - 60 times/min
Sorting Size		L ≤ 800W ≤ 500(L:material length, W:height)
Belt Surface Height		1000mm (also designed according to your need)
Weighing Conveyor Belt Size		according to your requirements
Detecting Way		unqualified alarm to stop
Power		AC220V ± 10%  50Hz  750W
Package	Dimension	1200*660*1355mm
	Weight	200KG
	Volume





Advantages -- Weight Checking Machine



1- KROEA SPG motor

2- Germany HBM digital load cell

3- TAIWAN GP touch screen

4- Motorized by three units of individual stepper, variable AA belts speed is adjustable separately as requests.

5- IP66 warterpoof protection and full stainless steel frame

6- Could be attached with any packaging line

7- Fast checking and feedback function

8- Memory function

9- Easy to operate

10-Rejecting system can be equipped(optional)



Optional Parts -- Weight Checking Machine







Packaging & Shipping -- Weight Checking Machine ee Powder Packing Machine

Our Promise of  Weight Checking Machine

Custom-made machine:

We have Great customized and design ability. Any required custom made machine can be

designed and manufactured for convenient operation and reasonable cost, making your

packaging system work smoothly.

Installation:

1- We provide videos and instruction manual to show the process of installation.

 2- We provide training for installation for free in our factory.

3- We can send technician to buyer's factory to install the machine and provide training service.

After Sales Service:

1- One year quality warranty and free lifetime technique support.

2- Free spare parts would be supplied if machine broken within warranty period.

3- After the warranty period, the spare parts for replacement are offered based on certain charge.



Thank you for your inquiry and we will provide packaging solutions according to

your requirements immediately.
