1000kg ton bags packing machine
Introduction--ton bags packing machine
1, The weighing system of CJD1000K quantification Ton packaging machinery contains high accuracy(0.02%) sensor and high resolution controller to keep the machine with high accuracy and stable performance.
2, The material feeding parts adopt two kinds(big one and small one) valves to control the three kinds feeding: fast, slow and exactness.
3, The packing range is 500-1200 kg adjustable. It suitable to big bags packing.
4, The parameter setting and the weighing calibration is very simple and with convenient operation.
Components--ton bags packing machine
1, Feeding part:Adopt two kinds(big one and small one) valves to control three kinds feeding:fast, slow and exactness.
2, Weighing shelf:conectted with sensor, and convey the weight signal to the electric box which controls the operation of the machinery.
3, The electromotion car operated by the motor and run in the track to convey the products.
The cars' position controlled by worker and the final position is determined by the limit switch.
4, Electirc box:Exterior signal and the sensor signal are conveyed to the electirc box, which could control the feeding ON and OFF, cylinder lifting and the car running through finished program.
Specification--ton bags packing machine
| Material | granule |
| weighing range | 500-1200kg |
| weighing speed | 4-6ton/hour |
| Accuracy | 0.1-0.3% |
| Machine dimension | L5200*W1800*H3500mm |
| Air supply | 0.4-0.6mpa 2m3/h |
Bag samples--ton bags packing machineder Filling Machine
1.what is your packing product?
2.what is the filling weight per bag?
3.what is the bag type and bag size? Could you provide any pics?
4.What is voltage and Hertz in your local?
Based on your more details, we will provide best packing solution for you.
