KIPOR 6.0KVA Air-cooled Super Silent Diesel Generator Set

KIPOR 6.0KVA Air-cooled Super Silent Diesel Generator Set photo-1
US$ 590 - 800 MOQ: 10 Sets
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
GBR
Model Number:
GD5
Payment & Shipping
Payment Methods:
Port of Shipment:
Fuzhou
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Fujian, China
Brand Name GBR
Model Number GD5
Output Type AC Single Phase
Speed 3000/3600RPM
Frequency 50/60HZ
Rated Power 6.0kva
Rated Voltage 230V
Rated Current 22.7A

KIPOR 6.0KVA Air-cooled Super Silent Diesel Generator Set





Product Description



    Using super light engine as the engine system, Low noise, low pollution,The stability of voltage and frequency, compact structural,The superior performance,Overload protection device will automatically shut down, To avoid the damage of the generator, The large capacity fuel tank provides a continuous operation for a long time.



      Diesel generator set can be used for important load without mains supply area facilities to provide power supply.



       Diesel generator set can be used for important load without mains supply region set up a complete set of equipment should be new, stable performance, reliable, durable, with a healthy start, signal remote control (including) and the start and stop, and other functions.





Generator Set Parameters



Generating set GDE7000ST
Rated Frequency Hz5060
Prime power Kva4.55
Standby powerKva55.5
Rated VoltageV230120/240
Rated Current A19.641.7/20.8
Rated rotation speedr/min30003600
Genetator
Genetator type GBR5 (190*140mm)GBR5 (190*140mm)
Pole No 22
Phase number Single phaseSingle phase
Excitation mode Self-excitation and constant voltage(with AVR)
Power factor COSΦ1.01.0
Insulation grade  BB
Engine
Engine type GD186FAEGD186FAE
Structure type single cylinder,in-lined,4-stroke,air cooled,direct-injected
Bore*strokemm86*7286*72
Engine displacement L0.4180.418
Compression ratio 19:0119:01
Rated powerkw5.76.3
Lubrication system Pressure splashed
Lube oild brand Above CD SAE 10W-30,15W-40
Lube capacityL1.651.65
Starter system 12V Electric system12V Electric system
Starting motor capacityV-KW12V  0.8KW12V  0.8KW
Charging motor capacityV-A12V  5A12V  5A
Battery capacityV-Ah12V 36Ah12V 36Ah
Fuel consumption ratiog/KW.h275.1281.5
Fuel typeEngine fuel consumption:0#(summer) -10#(winter) -35# (cold)
Genset
Panel type  Common panelCommon panel
OutputReceptacle2-Single phase2-Single phase
DC12V outputConnection pole outputConnection pole output
Nosie level(7m)dB(A)6868
Fuel tank capacityL1515
Overall dimensionmm900*565*750900*565*750
Net weighkg160/165160/165
Packing manner veneer board+carton box+pallet
Loading quantity / units:20': 72 units
40': 154 units







KIPOR 6.0KVA Air-cooled Super Silent Diesel Generator SetKIPOR 6.0KVA Air-cooled Super Silent Diesel Generator SetKIPOR 6.0KVA Air-cooled Super Silent Diesel Generator Set








Our Services





-Waranty



 1 year (1000 hours) from get goods.



-Technical support

 Technician online contact to support solution for generator maintain.

 If any question,pls send email or leave message to Technical Inquiry,they will reply within 24 hours.



-Spare parts support

 We support spare parts for our products,within the warranty,most of spare parts is free,but the Express charge

 cover by customer.



 Also,we support most of Chinese diesel generator parts,if you need any parts and the generator made from

 China,contact with our Technician,we will give you reply ASAP.



-Buying

 This service begin from 2012 for our customers,most of friend purchase so many products from other supplier,

 we support the service for collect goods and export all out,more detail,pls contact with our sales representative.
