Specifications
Bag Sealing Machine1- suitable for paper bags, multi-layer paper bags and PE bag
2- supply video,manual and training for free
Company Information -- Bag Sealing Machine
1- Anhui Yuanhong Machinery Automation Co.,Ltd is a high and new technology enterprise
which specialized in R&D and manufacture automatic packaging machine since 1995.
2- Main products are VFFS vertical packaing machine, weight machine, secondary automatic
packing machine(samll bags into big bag), vacuum packing machine, detecting and filling
machine, 1kg-50kg powder and granule bag packing machine, bags/bottles into box robot
palletizer, automatic packing line, bag-sewing machine and so on.
3- Especially the heavy bag (25kg-50kg) and secondary packing machine stay at advanced
level in the world.
WARMLY WELCOME TO VISIT OUR COMPANY !!!
Paper bag sealing and sewing machine of YH Series is suitable for paper bags, multi-layer paper
bag or paper and plastic composite (PE) bag packaging, the machine can be programmed to
automatically clean the dust of the bag mouth, trimming, sewing, trimming braid, paper tape
attaching, paper tape cutting , heat sealing, pressure and counting processes. By sealing, sewing,
paper tape attaching ,the heated and pressed bags has excellent sealing performance ,it can be
protected from dust, decay, pollution prevention, to make the packaging are properly protected.
Samples -- Bag Sealing Machine
Specifications -- Bag Sealing Machine
MODEL | YHS |
Power supply (V / Hz) | AC 220/50 or 110/60 |
Transmission power (W) | 0.4 |
Sealing Speed | CVT 7-12 |
Thin film materials | composite film, polyethylene, polypropylene |
Thin-film single-layer thickness (mm) | ≤ 0.4 |
Sealing width: (mm) | 810 |
Temperature range (℃) | 0-400 |
Sealing center to the ground height (mm) | 950-1450 |
Heat capacity (W) | 500 x 4 |
Cooling method | air-cooled |
Dimensions (L x W x H) (mm) | 2100 × 7500 × 1700 |
Net weight (Kg | 145 |
Details -- Bag Sealing Machine
Recommend Machine -- Bag Sealing Machine
Packaging & Shipping -- Bag Sealing Machine
OUR PROMISE of Bag Sealing Machine
Custom-made machine:
We have Great customized and design ability. Any required custom made machine can be
designed and manufactured for convenient operation and reasonable cost, making your
packaging system work smoothly.
Installation:
1- We provide videos and instruction manual to show the process of installation.
2- We provide training for installation for free in our factory.
3- We can send technician to buyer's factory to install the machine and provide training service.
After Sales Service:
1- One year quality warranty and free lifetime technique support.
2- Free spare parts would be supplied if machine broken within warranty period.
3- After the warranty period, the spare parts for replacement are offered based on certain charge.
Thank you for your inquiry and we will provide packaging solutions according to
your requirements immediately.
