Specifications
1.Baby care products packaging machine2.full automatic, easy to operate
3.can seal both up and down side
2014 China sell Baby care products packaging machine
Equipment profile:
This unit is the latest development of the new packaging machines, mainly to complete the delivery over packed bags from horizontal to vertical position to change, and then shaping, M side down, and finally sewing process package delivered. Achieved by a process of woven horizontal to vertical and then automatically stitch package. Replaces manual handling, artificial sewing process, saving manpower, material and financial investment, fully automated packaging. The device can be widely used in baby products, plastic products and other industries, is the preferred vertical bagging machine to complete the horizontal seam of the package.
Device basically consists of horizontal conveyor, rotating body, plastic body, inverted M side institutions, sewing organization, product transport and storage agencies and other institutions.
Production process: bags packed → → horizontal conveyor rotating mechanism (the bags down vertically from the horizontal) → → inverted M side shaping machine and transported → → automatic sewing machine woven products output.
The unit has the following advantages:
1 horizontal to achieve bags standing by the process;
2 automatic shaping function;
3 do M side and transported to sewing institutions;
4 The unit uses a touch-screen control, operation, specifications switch is very convenient, safe and reliable;
5 simple structure, stable performance, easy maintenance;
6 bags can meet a variety of specifications.
The main technical parameters:
1. This unit is suitable bags Specifications: L(1045-625) x w(442-350) x Thickness (100-240)mm;
2. Packaging materials: hard plastic bags, the size varies depending on the product;
3. Packing speed :10-14 bags / min;
4. Compressed air: 0.5 ~ 0.7MPa, the maximum air consumption 0.9 m3/min;
5. Power: 3KW 380V ± 10% 50Hz;
