Specifications
stainless steel beer tanks beer machine3 years warranty
CE,ISO certificate
OEM process,german technology
long life service
Stainless steel beer tanks high performance 3t-5t beer machine
Our company:
Shunlong Equipment Technology Co., Ltd. is a beer equipment manufacturer, and fermentation equipment manufacturers of Shandong. Professionally design, production, manufacture, installation, commissioning all kinds of beer equipment and facilities, including medium-sized beer saccharification, fermentation equipment, yeast expansion propagation, filter / filter press system, CIP cleaning system, high concentration dilution system, micro-brewed beer equipmentand equipment and filling equipment.
We mainly have the following kinds of equipment:50L/D,100L/D, 200L/D, 300L/D, 400l/D,500L/D,600L/D,800L/D, 1000L/D, 1200L/D,1500L/D,1800L/D,2000L/D, 2300L/D,2500L/D,3000L/D,5000L/Detc. We can produce the equipment according to clients’ requirments. Our equipment is mainly applied in hotels, bars, barbecue, small and medium-sized breweries and so on. As for the price, different products and specifications means various prices
Our beer equipment/microbrewery/brewhouse equipment introduction:
Complete beer equipment for microbreweries with production from 1000L up to 5000L of beer per day.
1000L | 2000L | 3000L | 4000L | 5000L brewhouse sizes are produced standartly, but also custom-made specially
composed brewhouses are manufactured on customer's request. Our brewing equipment enables production of all styles of beer. All brewing operations as well as fermenting & conditioning process can be controlled via semi-automatic-control with programming system, or can be fully automatic (computer controlled) depending on customer's requirements.
|
Model Items |
SL-1000 |
SL-2000 |
SL-3000 |
SL-4000 |
SL-5000 |
Capacity |
1000L/Day |
2000L/Day |
3000L/Day |
4000L/Day |
5000L/Day |
Area Request |
100M2 |
150M2 |
200M2 |
300M2 |
400M2 |
Installed Power |
15Kw |
20Kw |
25Kw |
35Kw |
40Kw |
Steam Request |
0.15Ton/Hr |
0.2Ton/Hr |
0.2Ton/Hr |
0.3Ton/Hr |
0.3Ton/Hr |
Water Consumption |
2M3/Day |
3M3/Day |
5M3/Day |
6M3/Day |
8M3/Day |
Red copper saccharification system
stainless steel mash tun
Beer factory equipment/beer plant specification list:
Name |
beer machine
|
|
mashing system |
01. mash & boil tank 02. lauter & whirlpool tank 03. mill machine 04. wort pump 05. plate heat exchanger 06. saccharification combination pipeline 07. pipeline & valve VLV 08. wort measuring meter 09. venturi tube 10. measuring cylinder 11. titanium rod 12. rake 13. operation platform |
voltage:380v material: sus304, thickness: 3.0mm External-Jacket(stainless steel), thickness:1.5mm;Cylinder (sharp type, SUS), thickness: 2.0mm. Inner surface treatment: welds grinded to Ra 0.6um. Insulation: Polyurethane-thickness 80m Adding: blender
|
fermentation system |
01. fermentation tank 02. bright beer tank(optional) 03. yeast adding tank 04. food tube 05. refrigerant pipelines(keep warm tube) 06. electromagnetic put air out 07. electronic gauges 08. valve pipe fittings |
Mareial Inner (SUS304)thickness: 3.0mm; External-Jacket(SUS304)thickness:1.5mm Oval head cone bottom, thickness: 2.0mm. Inner surface treatment: welds grinded to Ra 0.4um(attached Omni cleaning ball). Mirror surface finish inside. Insulation: Polyurethane-thickness 70mm. Equip with: cone 60degree resist compression design, dripping temperature drop. heat exchanger area: 0.1 sq.m Cleaning system: all round cleaning; Control method: temperatur control, voltage-control and hand automatic control. Weld slinging band, width 40mm Valve pipe fittings supporting, Single tank single control, Maitreya plate cooling jacket Bladder mechanical polishing, outer panel protection, weld slingjing band. |
cooling system |
01. Ice water tank 02. refrigerating unit 03. circulate pump 04. pipeline & valves |
material: Inner(SUS304), thickness: 2.5mm; External-Jacket(stainless steel); Insulation: Polyurethane-thickness 80mm |
control system |
01. mashing control 02. fermenting control 03. coling control 04. cleaning control |
Mannal operate Instrument Semi-Auto-control |
cleaning system |
01. Washing pump(moving) 02. Alkali tank 03. Sterilization tank |
1000l/h capacity: 300L SS anticorrosion pump, Power: 0.37kw lift: 18m Rev: 2880 r/min Stainless steel, thickness: 2mm Inner surface treatment: welds grinded to Ra 0.6um |
beer selling system |
01. beer-selling machine of bar counter |
4 nozzles 1 pc material: red copper Titanium valves Inner surface treatment: weld grinded to Ra 0.6um |
Our after sale service:
1.Providing beer production technology, brewing formula and person training service.
2.Providing cost analysis, brew house design, equipment production.
3.Implementation of turnkey projects, equipment, five years free warranty and provide technical
advisory services for many years.
4.Providing high-quality imported beer production materials, such as barley malt, wheat malt,
caramel malt, dark malt and hops, etc.
5.Provide other with beer production-related items such as beer kegs, liquor valves, etc.
beer equipment
what you can get form us ,get the new products ,and meet your processing requirements. our quality products help you to win more money and earn much time .we always do our best to save cost for you and ensure the quality goods. our rich -experience technical teams are standing by all the time . you can know the advance overseas technology form our products .which bring you more competitive andvantages
If you are interested in our equipment,you can contact me any time.
