HOGN-8H Transparent Meter Box

Name: HOGN-8H Transparent Meter Box
Brand: Hogn
Availability: InStock

FOB Price

US$ 5 - 30 / Piece

100 Pieces(Min. Order)

Port Ningbo/Shanghai Port
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China		Brand Name	Hogn
Model Number	HOGN-8H

Product Description

Specifications

1.High quality,fashion design.
2.Low price(5-30$)
3. Base: ABS&P.C.
4. Standard: GB17466-1998

Our company is specilize in electrical box for decades which are of high quality and low price

Productt performance:

1.good performance in insulation.

2.heat resistance.

3.waterproof.

4.aging resistance.

5.serge suppression.

rrosion resistance.

7.anti-UV.

Basic Data

Assembly components

Cover

Dimension Height*Width*Thickness (mm)

Single-phase Electronic Meter or Mechanical Meter 6pcs
P Vacuum Switchgear 6pcs
2-input 12-output Incoming Terminal 1pc

Transparent Polycarbonate

350*550*230

Performance:

Export Polycarbonate	Performance	ASTM Mathod	Unit	lr2200 lr2500 lr2700 lr3000
	Relative density	D792	%	1.2
	Hygroscopic coefficient in 24H water	D570	%	0.22~
	Luminousness 3mmthinkness in 23°C	D1003	Mpa	0.24
	Tensile strength	D638	%	85-89
	Tensile elongation	D638	kj/m	65-85
	IZOD impact strength (notched)3.2mm	D256		90-140 0.80-1.0
	Rokwell-hardness	D785		75-85
	Heat distortion temp.	D648	°C	134-135
	Coefficient of heat expansion 10^-5	D696	cm/cm/°C	6.0-6.5
	Shrinkage	D955	%	0.5-0.7
	Flammability	UI194		v-2

Flame retardant ABS engineering plactics					Flame retardant
	Properties	ASTM Method	Condition	Unit	PA-761	PA-765	PA-765A	PA-765B	PA-764	PA-764B
	tensile Strength	D-638	6mm/min	Kg/cm²	390 (5.530)	390 (5.530)	400 (5.670)	400 (5.670)	370 (5.250)	400 (5.810)
	tensile Elongation	D-638	6mm/min	%	30	15	15	25	15	20
	Flexural Modulus	D-790	2.8mm/min	10kg/cm²(10⁵ib/in²	2 (2.8)	21 (3.0)	2.3 (3.2)	2.4 (3.4)	2 (2.8)	2.3 (3.2)
	Flexural Strength	D-790	2.8mm/min	kg/cm2 (ib/in²⁾	580 (8.128)	620 (8.800)	640 (9.070)	650(9.200)	590(8.360)	660(9.370)
	Rokwell-hardness	D-785	1/8"	R-scale	R-96	R-100	R-100	R-102	R-96	R-102
	Vicat Softening Temp	D-1525	1.4"	Kg/cm/cm (ft-ib/in²)	21(3.9) 18(3.3)	22(4.0) 18(3.3)	24(4.4)20(3.7)	25(4.6)22(4.0)	14(2.6)12(2.2)	16(3.0)12(2.2)
	IZOD Impact Strength (Notched)	D-256	50°C/hr	°C	102(212)	90(194)	92(198)	92(198)	97(207)	101(214)
	Heat Distortion Temp.	D-648	annealed	°F	89(192)81(178)	83(181)73(163)	85(185)76(169)	85(185)76(169)	92(198)78(174)	93(199)80(176)
	Specific Gravity	D-792	unannealed	°C(°F) °C(°F)	1.2	1.19	1.17	1.16	1.19	1.16
	Melt Flow Index	D-1238 ISO-11333	23c	G/10min g/min	2.0 22	5.2 60	4.8 48	4.2 42	3.3	2.8 28
	Flammability	File No E56070 UL&C-UL	200°Cx5kg 220°Cx10kg	1/16"v-0 1/10"5VB	1/16"v-0 1/10"5VA	1/12V-0 1/10"5VA	1/12V-0 1/10"5VA	1/10"V-0 1/16"V-0 1/8"5VA	1/16"V-0 1/10"5VA	1/10"V-0 1/8"5VA
	Product description				F.R Medium impact	F.R high Hlow	F.R High Hlow	F.R Mediu Flow	F.R Weather Resistant	F.R Weather Resistant
