Home > Computer Products > Network Hardware & Parts > Network Switch > S2700-52P-EI-AC S2700 Series Ethernet Switches

S2700-52P-EI-AC S2700 Series Ethernet Switches

S2700-52P-EI-AC S2700 Series Ethernet Switches thumbnail-3

S2700-52P-EI-AC S2700 Series Ethernet Switches photo-1

S2700-52P-EI-AC S2700 Series Ethernet Switches photo-2

S2700-52P-EI-AC S2700 Series Ethernet Switches photo-3

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Products Status:

Stock

Transmission Rate:

Other, 5.4Mpps

Model Number:

S2700-52P-EI-AC

Contact Supplier Request Quote Chat Now

Guangzhou E-Energy Information Technology Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Products Status Stock

Transmission Rate Other, 5.4Mpps

Model Number S2700-52P-EI-AC

Place of Origin Guangdong, China

Specifications

S2700-52P-EI-AC mainframe( 4800MB RJ45, 4GB SFP, AC)

Product Specifications

Item	S2700-SI/S2710-SI*	S2700-EI	S2750-EI/S2751-EI
Downlink ports	S2700-9TP-SI**/S2700-9TP-EI/S2700-9TP-PWR-EI: 8 10/100Base-TX Ethernet ports S2700-18TP-SI/S2700-18TP-EI/S2750-20TP-PWR-EI-AC: 16 10/100Base-TX Ethernet ports S2700-26TP-SI/S2700-26TP-EI/S2700-26TP-PWR-EI/S2750-28TP-EI-AC/S2750-28TP-PWR-EI-AC/S2751-28TP-PWR-EI-AC: 24 10/100Base-TX Ethernet ports S2710-52P-SI/S2700-52P-EI: 48 10/100Base-TX Ethernet ports
Uplink ports	S2700-9TP-SI/S2700-9TP-EI/S2700-9TP-PWR-EI/: 1 dual-purpose 10/100/1000 or SFP S2700-18TP-EI /S2700-18TP-SI /S2700-26TP-EI /S2700-26TP-EI /S2700-26TP-PWR-EI/S2700-26TP-SI: 2 dual-purpose 10/100/1000 or SFP S2710-52P-SI/S2700-52P-EI/: 4 gigabit SFP S2750-20TP-PWR-EI /S2750-28TP-EI-AC/S2750-28TP-PWR-EI/S2751-28TP-PWR-EI: 2 Gig SFP and 2 dual-purpose 10/100/1000 or SFP
MAC address	8K MAC address entries Manual deletion of dynamic MAC address entries Aging time of MAC address configurable Blackhole MAC address entries	8K MAC address entries Manual deletion of dynamic MAC address entries Aging time of MAC address configurable Blackhole MAC address entries MAC address learning control which based on ports	16K MAC address entries Manual deletion of dynamic MAC address entries Aging time of MAC address configurable MAC address learning control which based on ports Blackhole MAC address entries
VLAN feature	4K VLANs, complying with IEEE 802.1Q Port-based VLAN assignment
VLAN feature	N/A	MAC address-based assignment Port-based QinQ
QoS	Outbound-Port-based rate limiting and flow-based rate limiting 4 or 8 queues of different priorities on each port Mapping between 802.1p priorities and queues SP, WRR, and SP+WRR algorithms	Port-based rate limiting and flow-based rate limiting 4 or 8 queues of different priorities on each port Mapping between 802.1p priorities and queues SP, WRR, and SP+WRR algorithms	Port-based rate limiting and flow-based rate limiting 8 queues of different priorities on each port Mapping between 802.1p priorities and queues SP, WRR, and SP+WRR algorithms
QoS	N/A		packet-based priority remark and packet redirection
IPv6 feature	IPv6 protocol Static IPv6 routes	IPv6 protocol Static IPv6 routes Supports MLD v1/v2 snooping.
Multicast	IGMP v1/v2/v3 snooping Port-based rate limiting for multicast packets	MVLAN Controllable multicast IGMP v1/v2/v3 snooping Port-based rate limiting for multicast packets
Reliability	S2700-SI:STP (IEEE 802.1d), RSTP (IEEE 802.1w) S2710-SI: STP (IEEE 802.1d), RSTP (IEEE 802.1w), MSTP (IEEE 802.1s)	STP (IEEE 802.1d), RSTP (IEEE 802.1w), MSTP (IEEE 802.1s), and RRPP topology and RRPP multi-instance	STP (IEEE 802.1d), RSTP (IEEE 802.1w), MSTP (IEEE 802.1s), and RRPP topology and RRPP multi-instance SEP and ERPS (G.8032) Smart Link tree topology and Smart Link multi-instance, implementing millisecond-level protective switchover
Traffic sampling	N/A		sFlow
Security & access features	S2700-SI:Storm suppression S2710-SI: Storm suppression , IP Source Guard	802.1x authentication and limit on the number of users on an interface Storm suppression IP Source Guard
Security & access features	S2700-SI:Multiple authentication methods including AAA, RADIUS, and TACACS+; Port isolation; Suppression of multicast, broadcast, and unknown unicast packets; CPU defense S2710-SI:Multiple authentication methods including AAA, RADIUS, and TACACS+; Port isolation; Suppression of multicast, broadcast, and unknown unicast packets; CPU defense; DHCP snooping	Multiple authentication methods including AAA authentication, RADIUS authentication, and TACACS+ authentication 802.1x authentication, MAC address authentication, MAC bypass authentication DHCP snooping Port isolation and sticky MAC Packet filtering based on MAC addresses Suppression of multicast, broadcast, and unknown unicast packets Limit on the number of learned MAC addresses CPU defense S2750-EI/S2751-EI:DHCP relay
Surge protection	Surge protection capability of service ports: 6 kV (The surge protection capability of service ports on PoE switches is 1 kV.)		Surge protection capability of service ports: 6 kV
Management	Stack (S2710-52P-SI-AC, S2710-52P-PWR-SI, S2700-52P-EI-AC, S2700-52P-PWR-EI) Auto-Config CLI-based configuration Remote configuration using Telnet SNMP V1/V2/V3 Remote network monitoring SSHv2 Web-based device management		Stack Easy Operation CLI-based configuration Remote configuration using Telnet SNMP V1/V2/V3 Remote network monitoring SSHv2 Web-based device management
Operating environment	Long-term operating temperature: –5°C to + 50°C Relative humidity: 10% to 90% (non-condensing)
Power	AC: Rated voltage range: 100 V to 240 V AC, 50/60 Hz Maximum voltage: 90 to 264 V AC, 50/60 Hz DC: Rated voltage range: –48 V to –60 V DC Maximum voltage range: –36 V to –72 V, DC Note: PoE models do not use DC power supplies.
Dimensions (W x D x H)	S2700-9TP-EI/SI: 250×180×43.6 S2700-9TP-PWR-EI: 320×220×43.6 S2700-18TP-EI/SI/ S2700-26TP-EI/SI/S2750-28TP-EI-AC: 442×220×43.6 S2700-26TP-PWR-EI: 442×420×43.6 S2710-52P-SI/S2700-52P-EI: 442×220×43.6 S2750-20TP-PWR-EI-AC/S2750-28TP-PWR-EI-AC/S2751-28TP-PWR-EI-AC: 442×310×43.6
Weight	S2700-9TP-SI<1.4 kg S2700-18TP-SI<2.4 kg S2700-26TP-SI<2.4 kg S2710-52P-SI<3 kg	S2700-9TP-EI<1.4 kg S2700-9TP-PWR-EI<2.5 kg S2700-18TP-EI<2.4 kg S2700-26TP-EI<2.4 kg S2700-52P-EI<3 kg S2700-26TP-PWR-EI<4 kg (without power supply)	S2750-20TP-PWR-EI<4.5 kg S2750-28TP-EI<3 kg S2750-28TP-PWR-EI<4.5 kg S2751-28TP-PWR-EI-AC<4.5 kg
Power consumption	S2700-9TP-SI<12.8 W S2700-18TP-SI<14.5 W S2700-26TP-SI<15.5 W S2710-52P-SI<38 W	S2700-9TP-EI<12.8 W S2700-9TP-PWR-EI<154 W (PoE: 124 W) S2700-18TP-EI<14.5 W S2700-26TP-EI<15.5 W S2700-52P-EI<38 W S2700-26TP-PWR-EI<808W (PoE: 740 W)	S2750-20TP-PWR-EI<440 W (PoE:375W) S2750-28TP-EI< 15.7 W S2750-28TP-PWR-EI< 445 W (PoE:370W) S2751-28TP-PWR-EI-AC<147 W (PoE:124W)
