Home > Manufacturing & Processing Machinery > Mixing Equipment > Mixing Tank > Vacuum Emulsifying Machine/Vacuum Homogenizer/emulsifier / Emulsifying Machine

Vacuum Emulsifying Machine/Vacuum Homogenizer/emulsifier / Emulsifying Machine

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Mixer Type:

Homogenizer

Product Type:

Cosmetic

Contact Supplier Request Quote Chat Now

Hangzhou Tiankai Import And Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai or Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Mixer Type Homogenizer

Product Type Cosmetic

Application Other

Additional Capabilities Milling

Place of Origin Zhejiang, China

Brand Name TK

Model Number 500L/1000L

Max. Loading Capacity 1000L

Voltage as to your requests

Dimension(L*W*H) as to workshop size

Warranty one year

After-sales Service Provided Engineers available to service machinery overseas

Brief introduction of configuration:

Homogenizer: homogenizer at the bottom of the mixing tank

Blending: anchor agitator blending with scraping device

Structure of main pot: structure with head at top and bottom

Method of heating and cooling: steam heating method, water cooling.

Control method of the whole set of machine: control panels manually

Lifting system

Discharging method of main pot: discharging by positive pressure, discharging by rotor pump……

Specification of configuration

No.	Commodity	Material, name and specification	Place of origin	Note
ONE: configuration
1	Main pot	Working volume: 500L; Total volume: 650L Structure: three layers of jacket with steam heating, preservation layer, and top and bottom heads.
a	Inner pot	Cylinder: construction material, stainless steel 316; thickness, 6mm. Head: construction material, stainless steel 316, thickness, 6mm	Import Made in China	Requirement of polishing: the inner surface should be polished to be Ra<0.4μm.
b	Jacket	Construction material, stainless steel 304, thickness: 5mm Heating: jacket with steam heating Cooling: jacket with cooling water	Made in China	With screw guide plate(baffle)
c	Outer jacket	Cylinder: construction material, stainless steel 304, thickness: 3mm Head: construction material, stainless steel 304, thickness: 3mm Preservation: by polyurethane foam, preserve heat during steam heating	Made in China	the outer surface should be polished to be Ra<0.8μm.
d	Pot cover	Head: construction material, stainless steel 316, thickness: 6mm One small inlet(DN25), one quick release filter One vacuum port(DN40); straight cross connection upon the vacuum port; one vacuum pressure gauge(Ø75) with construction material of stainless steel 304, dustproof asepsis respirator, vacuum pumping, evacuation, relief valve, quick open inlet(400), sight glass with scraping device, a whole array of manual valves and pipes.		the outer surface should be polished to be Ra<0.8μm. Full sanitary level SUS316L tube with2 clean balls
e	Blending	Power of the motor for blending: 4KW Rotation speed: 0-150 RPM.		Gear reducer ABB frequency controller
f	Blending blade	anchor agitator blending with scraping device, construction material, stainless steel 316 Construction material of scraper device: PTEF Thickness of blending blade: 10mm Baffle blade: construction material, stainless steel 316, thickness: 10mm
g	Mechanical seal	One set of mechanical seal	Germany	Borgman
h	Homogenizer at the bottom	Construction material, stainless steel 316, power of motor: 15 KW Rotation speed: 0-3600RPM	Germany	ABB motor ABB frequency controller
i	Mechanical seal	One set of mechanical seal(double mechanical, water cooling)	Germany	Borgman
j	Discharging port	Diameter of port: 2 inches
2	Pot for water phase	Working volume: 400L; Total volume: 550L Structure: three layers of jacket with steam heating, preservation layer, and top and bottom heads.
a	Inner port	Cylinder: construction material, stainless steel 316; thickness, 5mm. Head: construction material, stainless steel 316, thickness, 5mm	Import / Made in China	Requirement of polishing: the inner surface should be polished to be Ra<0.4μm.
b	Jacket	Construction material, stainless steel 304, thickness: 5mm Heating: jacket with steam heating	Made in China
c	Outer jacket	Cylinder: construction material, stainless steel 304, thickness: 3mm Head: construction material, stainless steel 304, thickness: 3mm Preservation: by polyurethane foam, preserve heat during steam heating	Made in China	the outer surface should be polished to be Ra<0.8μm.
d		Head: construction material, stainless steel 316, thickness: 5mm quick open inlet(400), dustproof asepsis respirator, one inlet(DN38) for water, all sanitary standard stainless steel 316 pipes for material contact parts.		the outer surface should be polished to be Ra<0.8μm.
e	Blending	Impeller blending: construction material, stainless steel 316	Made in China
f	Motor for blending	Power of motor: 2.2KW Rotation: 960RPM	Germany	ABB motor
g	Mechanical seal	One set of Borgman Mechanical seal.	Import	Germany
h	Discharging valve	Diameter of port: DN50
3	Pot of oil base	Working volume: 250L; Total volume: 300L Structure: three layers of jacket with steam heating, preservation layer, and top and bottom heads.		Inner polishing and outer polishing
a	Inner pot	Cylinder: construction material, stainless steel 316; thickness, 4mm. Head: construction material, stainless steel 316, thickness, 4mm	Import / Made in China	Requirement of polishing: the inner surface should be polished to be Ra<0.4μm.
b	Jacket	Construction material, stainless steel 304, thickness: 4mm Heating: jacket with steam heating	Made in China
c	Outer preservation	Cylinder: construction material, stainless steel 304, thickness: 3mm Head: construction material, stainless steel 304, thickness: 3mm Preservation: by polyurethane foam, preserve heat during steam heating	Made in China	the outer surface should be polished to be Ra<0.8μm.
d	Pot cover	Head: construction material, stainless steel 316, thickness: 6mm quick open inlet(400), dustproof asepsis respirator, all sanitary standard stainless steel 316 pipes for material contact parts.		the outer surface should be polished to be Ra<0.8μm.
e	Blending	Impeller blending: construction material, stainless steel 316
f	Motor of blending	Power of motor: 2.2 KW Rotation speed: 960 RPM		ABB motor ABB frequency controller
g	Mechanical seal	One set of Borgman mechanical seal	Import	Germany
h	Discharging valve	Diameter of port: DN50
4	Control panels	Construction material of the control box is stainless steel 304 with frequency inverter, TUOKE digital temperature controller, one whole set of Schneider electric components and buttons.
5	Cleaning pump	Raw water pump, power is 1.5 KW.
6	Vacuum pump	liquid-ring vacuum pump Power: 2.35KW Limiting vacuum: 33mbar Maximum vacuum speed: 80 m3/h

one-year maintenance free charge and all-life services
