Emergency Rescue Equipment Air Cushion Tools
Inflatable jump air cushion Technical Parameter
Model |
Size (M) |
weight(kg) |
inflatable time (s) |
Fill gas |
To undertake weight (kg) |
test |
Equipped |
XJD-P-16 |
5×4×2.5 |
78 |
≤42 |
≤10 |
≥75 |
≥16 |
Fan 1 cable tray 1 |
|
6×4×2.5 |
95 |
≤43 |
≤10 |
≥100 |
≥20 |
Fan 1 cable tray 1 |
|
8×6×2.5 |
165 |
≤48 |
≤10 |
≥110 |
≥30 |
Fan 2 cable tray 1 |
Blower technical indicators (also can be chosen for mobile fume extractor as wind source)
voltage (V) |
Fan Diameter (cm) |
frequency (HZ) |
power (kw) |
(m³/h) |
presssure (Pa) |
Rotate speed (r/min) |
Weight (kg) |
220 |
40 |
50 |
1.1 |
10800 |
290 |
2900 |
26 |
Fireproof fabric technology parameters
Weight g/m2 |
Strength of Extension (N/5cm) |
Lancinate Extension (N/5cm) |
Adhesive fastness (N/5cm) |
Flame ret. |
The Min. operation temperature (℃) |
The Max.Operation temperature(℃) |
||
|
Warp- Wise |
Broadwise |
Warp-Wise |
Broadwise |
|
|
|
|
520 |
2400 |
2100 |
300 |
300 |
60 |
28.2 |
-30 |
+70 |
Inflatable jump air cushion Feature
1.Lifesaving blowup lilo is a pick up to save from a height under the jump inflatable soft mat,
it can reduce the personnel during the landing impact, cushion and protection.
2.This company produces the lifesaving blowup lilo, special fire prevention cloth, fabrics
used by tough vinyl fiber lining, besmear outside imported fire retardant grinding combination
is made.Tensile high tear strength, has a flame retardant fire prevention, waterproof, corrosion
resistance, acid and alkali resistance, wear resistance, ageing resistance, oil resistant and cold
resistant, heat resistant properties, can be arbitrary folding.
3.The product structure is mainly divided into three parts: low pressure to undertake the upper
surface air cushion, emergency high voltage lower protection surface air cushion, independent
high speed blower connected air into the duct.Operation process is to use the fan to the air
cushion in about 50 seconds, inflatable make whole filled with air cushion, Can receive free fall.
Inflatable jump air cushion Advantage
1. The product surface haven't crease, each joint adopts advanced hot sealing technology, to strengthen all sealed,
reasonable structure specification, vents on the builtin import rubber band to avoid the leakage service life is longer,
the square of the vents makes it easier to flow out, make people fell more secure, technology leads the world level.
2. Free jumped off the staff falls on the cushion to undertake not rebound, can't touch the ground!
3. The personnel to jump on the air cushion, air cushion not dumping, not rollover!
4. Equipped with fan for professional machine, charging time is fast, more stable!
XunKai is professional manufacturer of rescue tools and firefighting equipment in china.We have many level rescue and protection tools.And as a factory,we can give more competitive dealer price to every customer.
In china,our main customer is government organization and some trade company.By tender or other way to have better cooperation with government organization.
Mono coupler,turbo function,double output,lightweight and multifunction is our rescue tools feature.
We have professional sales and technology team to solve any problem from our customer.Contact us!Let' talk details.
Warranty
1.One year warranty under normal use.We will be in charge for replacement or repair it for free if there is any problem caused by the tools quality( All fees are paid by XUNKAI)
2.24 hours technical support by Hhone,Email,Skype,MSN;
3.Friendly English working manual,popular and easy to understand.
4.XUNKAI provide sample
5. If you want to EXPO, you can advance to pay a small deposit, wait for after the exhibition, products have no quality problem, the deposit can be refunded
Countries We Exported to
Our products are exported to more than 20 countries, like USA, Italy, Ukraine, India, Indonesia, Philippine, Bangladesh,Turkey, South Africa, Nigeria,Sudan,Libya,Albania, France,Spain,Ecuador,Iran,Korea,Thailand etc.(You can understand the world)
Payment Terms
1. T/T in advance;
2. West Union:we can accept small payment(below$3000), but the banking charges shall be paid by the buyer;
3. L/C is acceptable if the amount is bigger than $100,000. Please issue the L/C draft for our confirmation first.
| Package Size for your caclulate freight | |
| Package Size | 80*28*23cm |
| Weight | 20kg |
| Delivery Time | |
| As normal,the delivery time is 5-7 working time since full payment (please contact sales representatives for exacttime each order) | |
