Manufacturer! minning hole rubber packer
- 0 per Month
- Tianjin China
- T/T
Product Details
Place of Origin: | Hebei, China | Brand Name: | HUAYU | Model Number: | hole rubber packer |
Product Description
Functions:
1. Moisture into the coal, the release of part of the gas, and effectively reduce the gas content of the coal.
2. Water injection to achieve the desired effect can be reduced more than 80% of the dust, and to improve workers' operating environment to prevent dust explosion.
3. Moist coal, prevention of coal spontaneous combustion.
4. High pressure water injection, broken coal, reduce fire and industrial products, reduce costs, and increase the sense of security of the workers.
5. Sealing broken coal, can effectively prevent the coal and gas outburst and explosion.
Structure:
Sealing consists of a high-pressure rubber expansion tube, safety valve quick connector.
Technical parameters:
Sealing diameter: 30-120mm (according to user demand for processing)
Working pressure: 1-8Mpa (according to user demand for processing)
Safety valve start pressure: 0.4-0.5Mpa
Work flow: water injection four tons -4.5 tons per hour
Sealing depth: 1M-8M
Hose expansion coefficient: 60% -100%,
The use of methods and precautions:
1, the use of coal seam water injection sealing fast, simple, just the job site waterway connectivity and sealing, the sealing device is fully inserted into the bore hole, under a certain pressure, the sealing device hose expansion to achieve sealing, water broken coal.
2 Coal Seam Water sealing device can be repeatedly used several times after water injection relieved the pressure, the sealing can be recovered, remove the sealing device.
3, send plug sealing and recycling sealing non-pressurized operation.
Sealing is working in front of the exclusion of anyone operating.
Some datas for your reference
Specifications | ID mm | OD mm | Aperture mm | Expansion range mm | Mpa W.P | MPa | ||
≥ T.P | ≥ B.P | |||||||
φ16-2 | 16±0.5 | 30±1.5 | 40 | 50 | +8 -2 | 8 | 16 | 32 |
φ16-4 | 16±0.5 | 36±1.5 | 40 | 50 | +8 -2 | 20 | 30 | 40 |
φ19-2 | 19±0.5 | 36±1.5 | 45 | 60 | +8 -2 | 8 | 16 | 32 |
φ19-4 | 19±0.5 | 40±2.0 | 45 | 60 | +8 -2 | 20 | 30 | 40 |
φ22-2 | 22±0.5 | 39±2.0 | 50 | 80 | +8 -4 | 6 | 12 | 24 |
φ22-4 | 22±0.5 | 45±2.0 | 50 | 80 | +8 -4 | 20 | 30 | 40 |
φ32-2 | 32±0.5 | 50±2.0 | 60 | 90 | +8 -4 | 6 | 12 | 24 |
φ38-2 | 38±0.5 | 55±2.0 | 65 | 95 | +8 -4 | 5 | 10 | 20 |
φ45-2 | 45±0.5 | 63±2.0 | 75 | 100 | +8 -4 | 4 | 8 | 16 |
φ45-4 | 45±0.5 | 69±2.0 | 75 | 100 | +8 -4 | 16 | 24 | 32 |
φ51-2 | 51±0.5 | 69±2.0 | 90 | 110 | +8 -4 | 4 | 8 | 16 |
φ51-4 | 51±0.5 | 75±2.0 | 90 | 110 | +8 -4 | 16 | 24 | 32 |
φ64-2 | 64±0.5 | 84±2.0 | 100 | 120 | +8 -4 | 3 | 6 | 12 |
φ64-4 | 64±0.5 | 90±2.0 | 100 | 120 | +8 -4 | 8 | 12 | 16 |
φ76-2 | 76±0.5 | 94±2.0 | 110 | 130 | +8 -5 | 3 | 6 | 12 |
φ76-4 | 76±0.5 | 99±2.0 | 110 | 130 | +8 -5 | 8 | 12 | 16 |
φ89-2 | 89±0.5 | 109±2.0 | 130 | 140 | +8 -5 | 3 | 6 | 12 |
φ102-2 | 102±0.5 | 122±2.0 | 150 | 160 | +8 -5 | 3 | 6 | 12 |
Mainly produces:
1. Resistance burning antistatic high pressure steel wire spiral rubber hose, high pressure braided hose, high temperature resistant rubber hose,CONCRETE PUMP HOSE.
2. Super high pressure steel wire hose and high pressure hose assembly.
3. Drilling hose,Floating Dredging Hose,Marine oil hose large caliber,Dredger Hose,Flame resistant hose,Dredger Suction and Discharge Hose.
4. Oil field special rubber seals.
5. Solid control parts: Hammer Union, Air Grip Unions, mud tank unions.
6. Air Operated Thread Protectors,Mech-Tec (TM)Clamp-On Thread Protectors.
The company since its inception, relying on science and technology for development. Established long-term cooperative relations with chemical shenyang rubber research institute, has the research, development, production of hundreds of special rubber products, in the domestic each big oil fields, steel mills, mining, machinery and other industries has been the user's consistent high praise, and exported to South Korea, Mongolia, Russia and other countries.
Any needs for API 7K Drilling hose, Concrete hose, High pressure hose, hydraulic hose and Hammer Union, just contact me!
