22R Crankshaft for Toyota

22R Crankshaft for Toyota thumbnail-1
22R Crankshaft for Toyota thumbnail-2
22R Crankshaft for Toyota thumbnail-3
22R Crankshaft for Toyota thumbnail-4
22R Crankshaft for Toyota thumbnail-5
22R Crankshaft for Toyota thumbnail-6
22R Crankshaft for Toyota photo-1
22R Crankshaft for Toyota photo-2
22R Crankshaft for Toyota photo-3
22R Crankshaft for Toyota photo-4
22R Crankshaft for Toyota photo-5
22R Crankshaft for Toyota photo-6
US$ 1 - 500 MOQ: 20 Sets
Key Specifications
Get Latest Price
Type:
Crankshaft
Car Make:
Toyota
OE NO.:
Toyota
Contact Supplier Request Quote Chat Now
Shenyang SWIFT Auto Parts Trading Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
DALIAN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Crankshaft
Car Make Toyota
OE NO. Toyota
Place of Origin Liaoning, China
Brand Name POC
Model Number 22R, 22R
Warranty 12 Months
Product Description

Brand Name:POC

Model Number:22R

Type:Piston Cylinder

Place of Oringin:China

Car Make: Toyota

Packaging & Delivery

Packaging Details:CARTON OR WOODEN CASE

Delivery Detail:WITH 15 DAYS AFTER DEPOSIT

22R
The 8-valve SOHC 2.4 L (2,366 cc) 22R was produced from 1981 through 1997.
Cylinder bore was 91.9 mm (3.62 in) and stroke was 88.9 mm (3.5 in).

Initial output was 97 hp (72 kW) at 4,800 rpm and 129 lb·ft (174 N·m) at 2,800 rpm.
By 1990 the 22R was producing 108 hp (81 kW) at 5,000 rpm and 138 lb·ft (187 N·m) at 3,400 rpm.


22R-E engine fitted in a 1989 Hilux Surf
The first fuel injected 22R-E engines appeared in August 1982.
Output of these engines is commonly rated at 105 hp (78 kW) at 4,800 rpm and 137 lb·ft (185 N·m) at 2,800 rpm.

In 1985, the engine was significantly reworked, output was up to 114 hp (84 kW) at 4,800 rpm and 140 lb·ft (190 N·m) at 3,600 rpm. Many parts from the newer 22R-E are not compatible with those from the older pre-1985 engine. Non-compatible parts include the cylinder head, block, pistons and many of the associated parts such as the timing chain and cover, and water and oil pumps (although the oil pump internals are the same). These changes also affected the 22R, therefore one can consider the 85-95 22R-E as a fuel injected version of the 85-90 22R with only minor differences, if any.

Toyota swapped the dual-row timing chain used in older engines for a single-row chain with plastic guides in 1983. This system reduced drag on the engine, but is occasionally problematic. Every 80,000 to 140,000 miles, the chain will sometimes stretch to the point that the hydraulic-operated chain tensioner cannot take up any more slack. When this happens, the timing chain impacts the solid-plastic driver's side chain guide, breaking it within a few hundred miles of driving and creating a noticeable chattering sound in the front of the engine, especially when cold. If the engine continues to be operated after the guide breaks, the chain will stretch rapidly (an unfortunate characteristic of single row chains). The loose chain will cause inaccurate ignition timing, which usually results in noticeably rough running. In continued operation, the chain can jump a tooth on the drive sprocket or break entirely, with either case resulting in engine damage from valve/piston collisions. Also, the stretched chain will slap against the side of the timing cover, due to the broken guide, wear through the cover and into the coolant passage behind the water pump. This will cause coolant to drain into the crankcase/oil pan, possibly causing damage to internal engine components such as bearings, crankshaft and valve train, as well as damage caused by overheating due to the lack of coolant (since it has drained into the engine oil). The condition can also render a misdiagnosis of a head gasket failure when, in fact, the head gasket may still be good. The best fix is to buy an aftermarket timing-chain kit (with steel-backed guides) and a new timing cover; 'patching' the hole in a worn timing cover is strongly discouraged.

The turbocharged 22R-TE (sold from late 1985 through 1988) produced 135 hp (101 kW) at 4,800 rpm and 173 lb·ft (234 N·m) at 2,800 rpm.

These engines are extremely well known for their durability, decent fuel efficiency and good low to mid range torque.

However, its weakness is high-end power. The 22R has a large displacement and a strong block, but its comparatively long stroke and restrictive head limit its use in high revving applications. Thus, the Toyota 18R-G, 2T-G, 4A-GE and 3S-GE 4-cylinder engines are better suited for performance applications.

A popular modification to the 22R is to use a 20R head. This head has smaller combustion chambers, giving a higher compression ratio, which then allows more power to be developed. The 20R head also flows better than the 22R head, which improves high RPM power. The 20R head is a simple bolt-on modification for the pre-1985 block, but also requires the use of the 20R intake manifold, making it impossible to use with the 22RE EFI system.[19] For blocks 1985 and onwards, further modifications are required.

CodePower kW (hp)Torque N·m (lb·ft)YearsComments
22R72 (97) at 4,800 rpm174 (129) & 2,800 rpm1981–1990carb, dual row timing chain ('81-'82)
carb, single row timing chain ('83-'90)

22R81 (108) at 5,000 rpm187 (138) & 3,400 rpm1990–1995
22R-E78 (105) at 4,800 rpm185 (137) & 2,800 rpm1983–1984EFI, single row timing chain
22R-E84 (114) at 4,800 rpm190 (140) & 3,600 rpm1985–1997EFI, single row timing chain
22R-TE101 (135) at 4,800 rpm234 (173) & 2,800 rpm1986–1988turbocharged, single row timing chain
Applications:

22R
1981 Toyota Corona
1981-1988 Toyota Hilux
1981-1984 Toyota Celica
1991 Toyota Cressida
1981-1995 Toyota Pickup
1984 Toyota 4Runner
22R-E
1985-1995 Toyota Hilux
1983-1985 Toyota Celica
1983-1987 Toyota Corona RT142
1984-1995 Toyota Pickup
1985-1995 Toyota 4Runner
1989-1997 Volkswagen Taro
22R-TE
late 1985-1988 Toyota Hilux, 135 hp (101 kW)
1986-1987 Toyota 4Runner
Company Information

Shenyang swift Auto Parts Trading Co. Ltd., Belong to Shenyang aerospace Yuxing Machinery Manufactury.The later is a subsidiary of Chinese Aerospace Science and Industry Corporation gro.Our main product are  engines and vehicle parts.All of our products comply with international quality standards, and export to many countries. We have obtained  ISO9001: 2000  and ISO / TS16949: 2002 certification up.

"Excellence quality, Exceed customer expectations"are our guidelines .Welcome to visit our factory and discuss cooperation with us.
