PG-5 Cable Stripper Ratchet wheel type stripper
Ratchet wheel type stripper PG-5
Capacity:Diameter:above 25mm,1.0lnch
Ratchet wheel type stripper PG-5
For more than 25.00mm diameter circle cable skinning.
Various insulation layer can be stripped completely.
Suitable for vertical cutting and cutting around.
Most adjustable cutting depth to 5mm.
Replaceable blade(can be used on both sides)
Cutter arbor used glass fiber reinforce with material made of pplyester.
PG-5 Cable Stripper for Stripping 25mm Comm/PVC/LV/MV Cables,for longitudinal and circular cutting Operation Method.
For removing all layers of insulation on cables with diameters of over 25mm , applicable for communication cable, MV cable(PVC constructed), LV cable(PVC insulation), MV cable(PVC insulation).
Suitable for longitudinal and circular cutting, Cutting depth can be adjusted from 0 -5mm, Replaceable blade (both sides can be used)
By using the adjusting screw, the cutting depth (0 -5mm ) can be adjusted according to the thickness of the outer insulation.
• To begin cutting in either direction, the blade is pressed and guided by operator's thumb.
• The cutting of the outer insulation is achieved by means of small movements and pressure on gear towards the insulation at the same time.
• In order to remove the joint of the insulation the blade must be pressed into the insulation.
• Changing the blade: By removing the adjusting screw the double-ended blade can be changed.
