Chicken Nuggets Production Line

Chicken Nuggets Production Line photo-1
US$ 10,000 - 150,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New, New
Place of Origin:
Shandong, China
Brand Name:
XINXUDONG
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao port China
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Shandong, China
Brand Name XINXUDONG
Model Number XDL-8500*600
Application Other, frozen chicken nuggets processing line, frying food
Voltage 380v
Power(W) 240kw
Weight 3.5ton
Dimension(L*W*H) 8500*1350*2200
Certification CE.ISO9001, CE,ISO9001
Warranty One year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.fried chicken fryer
2.simple, safe, easy to clean and maintenance, saving oil
3.raw material:SUS304
4.healthy&environmental

 MAIN PRODUCT:FRYING PRODUCTION LINE

1.made by stainless steels
2.automatic oil temperature control
3.filter the dreg automatically
nvenience washing





XDFL-5500*500 deep fryer
The deep fryers for fast food are specially developed for restaurants and fast food shops .



XDFL-5500*500 deep fryer

The deep fryers for fast food are specially developed for restaurants and fast food shops .They can fry many kinds of foods,such as bakemeat,chicken,fresh chips,samosa,pie,twisted cruller,Chinese style,spring roll and some other snacks.

  • Made by stainless steels.
  • With the double frying areas,you can set up different frying temperature
  • With water-oil blending technology it can filter the dregs automaticallu.
  • Automatic oil-temperature controlling system
  • Electricity leaking protector
  • It can frying many kinds of food at one time and the taste of food will not be mixed each oyher
  • Less oil smoke and environmental protection

size-  5500×1250×2200mm

frying area- 4300×500mm

oil capacity-820L

power-120KW

voltage-380V50HZ

temperature range- 0~260




Product Description



1.The advanced heating tube,can stand 1600 centigrade heating for more than three years.Smart temperature control,when temperature exceed 10 centigrade up the setting temperature,the system automatically cut off the power supply.When the temperature exceed 10 centigrade below the setting temperature,the system start the power supply.



Chicken Nuggets Production lineChicken Nuggets Production line



2.The PTFE BELT in the first part is 1.5 meter to avoid the products adhere to the belt.

Chicken Nuggets Production line

Chicken Nuggets Production line


3. The continuous double mesh belt ,the products between two double mesh belt were convey from one side to another size in the smooth and steady speed and  the same temperature.

Chicken Nuggets Production line

4.Oil circulation filter system, the high temperature circulation pump supply the power for circulation.The coarse filtration system and continuous ultra-filtration system.

Chicken Nuggets Production line



4. Residue Scraping  board system

can take away the impurities in the bottom of frying production line.

Chicken Nuggets Production line

 5Hoisting system of the chain

The chain hoisting system can hoist the mesh belt and heating tube, leave nothing in the frying production line.Make it easy to clean the frying line container.

Chicken Nuggets Production line

6.Automatic platoon lampblack system to guarantee the workers have a good-working environment.

Chicken Nuggets Production line



7.Electronic control system

Make the control more smart and automatical.

 Chicken Nuggets Production line

 The whole line:

Chicken Nuggets Production line

Chicken Nuggets Production line

 Chicken Nuggets Production line

 Chicken Nuggets Production line

 Chicken Nuggets Production line
