Supply Ignition Coil Tester---best Price
US$ 1 - 2
MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
Other, Original diagnostic tools
Voltage:
v
Power:
w
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Ignition Coil Tester---profesinonalUS$ 1 - 2MOQ: 1 Set -
Auto Diagnostic Tool Launch X431 TOPUS$ 1 - 2MOQ: 1 Set
-
Launch X431 Master -------in Stock With Optimum PriceUS$ 1 - 5MOQ: 1 Set
-
Optimum Price to Launch X431 MasterUS$ 1 - 5MOQ: 1 Set
-
Precio Optimo Para Launch X431 MasterUS$ 1 - 5MOQ: 1 Set
Type
Other, Original diagnostic tools
Voltage
v
Power
w
Certification
FCC
Place of Origin
Guangdong, China
Brand Name
reliable
Model Number
Ignition Coil Tester
Warranty
one year
Specifications
Fast, simple and accurate of way to determine the defects in the ignition coils....Model Number: Ignition Coil Tester
Function:
• Fast, simple and accurate of way to determine the defects in the ignition coils.
• Automatic distinguish different ignition coil type by auto switching control modes.
• Adjustable Frequency control ranging from 120Hz ~ 12 KHz.
• Safety and foolproof.
• Applicable on coil-on-plug (COP), coil-near- plug (CNP), double ended coil-on-plug (DECOP) or wasted plug systems.
Simple Operation:
• Connect power from 12Volts car battery and the power LED will light up.
• Insert the yellow banana plug to the yellow socket and connect the cable to the control terminal of the ignition coil.
• Hook up the spark tester to the ignition coil.
• Turn ON the frequency knob and adjust the frequency from low to high (clockwise).
• Turn back to low frequency and observe the spark color which should be bluish purple.
• Increase the frequency gradually and observe the spark line. It should be in a straight line when NORMAL. If the spark line is curved, it indicates that the coil is aging or there is an internal leakage.
• Turn to maximum frequency until the coil is slightly warm, then turn down the frequency and observe the spark line whether it is continuous or intermittent. If arcing sound is heard but no spark indicates that there is internal leakage.
• Use Ignition Leak Checker to detect the source of the leak.
The Package Contains:
Main Spark generator unit - 1 unit
Spark Tester - 2 units
Extension probes (red & black) - 2pcs (1 each)
Ignition Leak Checker 1 unit
Extension cable (red, blue, green & black) 4pcs (1 each)
Crocodile Clip (red & black) 2pcs (1 each)
3mm Female terminal cable 4 pcs
5mm Female terminal cable 2 pcs
Carry case - 1 pc.
Carry case - 1 pc.
