Specifications
Power: 1W-500WPThin Film Solar Panel:High performance
Warranty:25 years lifetime
Certificate:TUV,UL
high quality best price thin film solar module with TUV (Amorphous silicon solar panels, a-Si solar panel, a-Si solar module,amorphous silicon solar pv module, a-Si thin film solar panel,amorphous silicon thin film solar panel power range from 1Watts to 100Watts)
a-Si Thin Film Solar Panel/Module
1. Product Description:
• The price of amorphous silicon solar panel is competitive than silicon solar panel. It can be promoted in large scale.
• Amorphous silicon solar panel has advantages as high voltage, good charging ability and workable under weak sunlight. In other words, it has good quality and competitive price compared with silicon solar panel.
• To actual test results, amorphous silicon solar panel can prduce more than 10% to 20% energy per year than silicon solar panel of the same power, especially in the area which has many overcast and rainy days.
2. Other Products and OEM
Our related products: solar panel system, solar street light, solar lamn lamp, solar yard light. Please visit our company page for more on info.
We offer OEM service too, contact us for further info.
3.Technical Parameter:
Solar Panel Specifications (Test condition: 1000W/m2, AM1.5, 25°C)
| Solar Module | a-Si Thin Film Solar Panel/Module | ||
| Maximum power (Wp) | 90 w | 95 w | 100 w |
Maximum power voltage (V) | 97.20 | 104.00 | 104.80 |
Maximum power current (A) | 0.92 | 0.91 | 0.95 |
| Open circuit voltage (V) | 130.20 | 131.00 | 132.80 |
| Short circuit current (A) | 1.10 | 1.00 | 1.19 |
| Size of module (mm) | 1309x1109x35 | 1309x1109x35 | 1309x1109x35 |
| Type of Solar Cells | a-Si single junction | ||
| Maximum system voltage (V) | ≤1000 VDC | ||
| Temperature coefficients of Isc (%) | + 0.09/ °C | ||
| Temperature coefficients of Voc (%) | -0.28/ °C | ||
| Temperature coefficients of Pm (%) | -0.20/ °C | ||
| Temperature coefficients of Im (%) | +0.09/ °C | ||
| Temperature coefficients of Vm (%) | -0.28/ °C | ||
| Temperature Range | -40°C~+85°C | ||
| Surface Maximum Load Capacity | 60m/s(200kg/sq.m) | ||
| Allowable Hail Load | steel ball fall down from 1m height | ||
| Weight per piece (kg) | 18.00 | 18.00 | 18.00 |
| Junction Box Type | Junction box with TUV certificate | ||
| Length of Cables (mm) | as customer's demand | ||
| Module Efficiency (%) | 6.6% | 7.0% | 7.3% |
| Output tolerance (%) | ±5% | ||
| Frame (Material, Corners, etc.) | Aluminum Alloy Frame | ||
| Standard Test Conditions | AM 1.5,1000W/m2, 25°C | ||
Warranty
| 5 years product warranty and 20 years 80% of power,25 years for lifetime | ||
4. Why choose us?
(1)Superior quality
• 10 years warranty for solar panel and its materials and corresponding fittings.
• 90% output of rated power after 10 years
• 80% output of rated power after 25 years under Standardest Conditions
(2) Price is competitive
• We are professional manufacturer of solar panels in China for 5 years, so we can provide factory direct price of solar panels
• The prices can be ranged from US$0.8-0.98/W. I believe it will allow you to compare with other companies in China
(3) Packaging advantages
Excellent package can avoid the broken incidents during long-distance transportation. Prompt delivery will save your precious time
(4) Service is the soul of an enterprise
•The customer is king.
• We can accept small sample order and also can produce products according to clients' requirements.
• Any question or requirement will be replied within 24 hours
• Our company philosophy is built around two simple ideals:quality and responsiveness
5.Trade and Market
North America, South America, Eastern Europe, Southeast Asia Africa, Oceania, Mid East, Eastern Asia, Western Europe,
Central America, Northern Europe, Southern Europe
6. Factory Show
(1) Manufacturing
(2) Our Packing
(3) Our products can be used in these fields
Universality of Applications can provide you many chances to branch out your business.
(5) Our activity in SNEC PV 2012
(6) Our Company
Our company is factory specializing in R&D, manufacturing , sales & service of
5Wp-320Wp mono-crystalline and poly-crystalline solar modules.
Hilight-Solar: Power your future!
Here you can enjoy the best price and
the highest quality, no doubt that you will get the maximum profit !
Any question please do not hesitate and feel free to contact us. ^_^
If you contact us as below, we will not let you down!
