Linear Bearing Lm10uu
- Shenzhen
- T/T L/C Credit Card PayPal
You May Like
Product Details
| Brand Name | neutral | Precision Rating | ABEC1,ABEC3,ABEC5,ABEC7,ABEC9,P0,P6,P5,P4,P2 | |
| Model Number | lm10uu | Place of Origin | Guangdong, China |
Product Description
Specifications
1.linear bearing lm10uu2.ISO9001:2008 Quality
3.OEM service
4.18 years SGS audited bearing manufacture
linear bearing lm10uu Specifications
1)Model #: LM10UU
2)Weight : 0.030 kg
3)dr: 10mm
4)D: 19mm
5)L: 29mm
6)Bearing rows: 4
linear bearing lm10uu Packaging & Delivery
| Packaging Detail: | the standard export packing |
| Delivery Detail: | 3-5 days We can offer almost types of linear bearing(LM,LME,LMF,LMH,LMK,KH,etc)Size range is from ID6-60mm Linear motion bearings have the characterized of smooth movement,low friction,high rigidity and long life span,economical and easy to maintain or replace. Size:6-60mm Modle No:LM,LME,LMB,etc |
| linear bearing lm10uu are the most common bearing type.they accomomodate both radial and axial loads in both directions and are suitable for high rotational speeds. | ||
|---|---|---|
| linear bearing lm10uu | ||
| Greese: | As your requirement, such as SRL, PS2, Alvania R12 and so on. | |
| Quality Standard: | ISO9001:2008 quality management system | |
| Features: | 1)Precision: ABEC-1(P0), ABEC-3(P6), ABEC-5(P5), ABEC-7(P4) | |
| 2)Vibration Level: V1, V2, V3, V4 | ||
| 3)Clearance: C2, C3, C4, C5 | ||
| 4)Hardness: 59-63 HRC | ||
| 5)Cage: steel, Brass | ||
| Technology & QC Process: | 1. Assembly | |
| 2. Windage test | ||
| 3. Cleaning | ||
| 4. Rotary Test | ||
| 5. Greasing and gland | ||
| 6. Noise Inspection | ||
| 7. Appearance Inspection | ||
| 8. Rust Prevention | ||
| 1. Industrial packaging. | ||
| Packaging Details: | 2. According to the requirements of packaging. | |
| Delivery Detail: |
| |
| Payment terms: | A:100% TT | |
| B: 30% T/T in advance .70% against copy of B/L | ||
| C: 30% T/T in advance .70% L/C | ||
| D:Western union | ||
| E: L/C,D/A,D/P,T/T,Western Union,MoneyGram,paypal. | ||
| Application: | Auto, tractor, machine tool, electric machine, water pump, agricultural machinery and texile machinery ect. | |
| Service: | We will follow up on our customers' feedback and suggestions after every delivery and we make every effort to solve their problems in order to ensure their total satisfaction. | |
linear bearing lm10uu Quality Control:
Our company inspecter will check the products one by one before we sent it out, and we can also follow customers' special requests to control the quality. We have got little feedback of quality issue from customers these years. So please rest assure.
About us:
Shenzhen Xinchangsheng hardware CO,Ltd, was founded in 1995. We specialize in producing all kinds of bearings for 18 years. 65% of bearings export to Europe, North America, South America, Southeast Asia, South Asia, Middle east and other countries and regions.We accept customization , just tell me what's material and package you want. Huge stocks and sample are available for you. If you are interested in our products , welcome to contact us!
We accept customization, I will go through all the questions with you!
