Product Details
| Place of Origin | Shandong, China | Brand Name | Hilight, Hilight | |
| Model Number | HSPV-P-230W, HSPV-P-230W | Material | Polycrystalline Silicon | |
| Size | 1640*992*40mm | Number of Cells | 60 | |
| Max. Power | 235W |
Product Description
----- High Quality Solcellepanel ---------
1.Long-term stability and reliability.
2.High cell efficiency with good-quality crystal silicon materials.
3. High transmit , low-iron tempered glass with enhanced stiffness and impact resistance.
4. Unique frame designed with high mechanical strength for easy Installation and durable requirement
5. Advanced encapsulation materials to provide efficient protection from various environmental conditions.
----- Specification of 230w Solcellepanel -------
| Module Type | HSPV225Wp-156-60P | HSPV230Wp-156-60P | HSPV235Wp-156-60P |
| Maximum power at STC (Pmax) | 225w | 230w | 235w |
| Maximum power voltage (Vmp) | 29.5 | 29.6 | 29.7 |
| Maximum power current (Imp) | 7.63 | 7.77 | 7.91 |
| Open circuit voltage (Voc) | 35.8 | 35.8 | 35.8 |
| Short circuit current (Isc) | 8.34 | 8.57 | 8.70 |
| Nominal Operating Cell Temperature | 45 ± 2°C | ||
| Temperature coefficients of Isc | +0.049% /°C | ||
| Temperature coefficients of Voc | -0.340% /°C | ||
| Temperature coefficients of Pmax | -0.430% /°C | ||
| Standard Test Conditions (STC) | Irradiance 1000W/m2, Module temperature 25°C, Air Mass (AM)=1.5 | ||
| Power Production Tolerance | ± 3% | ||
All the photos are live-action shooting !
