DJI S900 COMBO D

Specifications

(ASSEMBLE & TESTING SERVICES)

DJI has recently added to its large line of flying camera drones with the new Spreading Wings S900. The new aerial system lands in DJI's professional range between the previously released S800 and the S1000. The company describes it as a "distillation of our latest technology into a lightweight, easy to carry platform."

The S900's light weight is due to its sturdy carbon fiber arms and retractable landing gear, according to DJI, which has also made the actual arms able to fold in for easy transportation as well. Once set-up, which apparently takes about 5 mins, you'll get around 18 mins of flying time with a take off weight of about 8.2kg. That flight duration is based on using a 6S 12000mAh battery.

It also features six of the company's "most powerful motors," handling and steering enhancements, the AS150 sparkproof plug to prevent short circuits, customizations upgrades and more. Like DJI's other drone options, this one is also compatible with a wide range of its own camera gimbals including the Zenmuse Z15, GH3, GH4, and BMPCC.

Specifications

Frame

Diagonal Wheelbase 900mm

Frame Arm Length 358mm

Frame Arm Weight (Including Motor, ESC, Propeller ) 316g

Center Frame Diameter 272mm

Center Frame Weight (With Landing Gear Mounting Base, Servos) 1185g

Landing Gear Size 460mm(Length)×450mm(Width)×360mm(Height)

Motor

Stator Size 41×14mm KV 400rpm/V

Max Power 500W

Weight (With Cooling Fan) 158g

ESC

Working Current 40A

Working Voltage 6S LiPo

Signal Frequency 30Hz ~ 450Hz

Drive PWM Frequency 8KHz

Weight (With Radiators) 35g

Foldable Propeller (1552/1552R)

Material High strength performance engineered plastics

Size 15×5.2inch

Weight 13g

Flight Parameters

Takeoff Weight 4.7Kg ~ 8.2Kg

Total Weight 3.3Kg

Power Battery LiPo (6S,10000mAh~15000mAh,15C(Min))

Max Power Consumption 3000W

Hover Power Consumption 1000W (6.8Kg Takeoff Weight)

Hover Time 18min (12000mAh& 6.8Kg Takeoff Weight)

Working Environment Temperature -10 °C ~ +40 °C
