Nitrogen gas filling machine
This machine can use for coffee packing machine, such as K-cup coffee capsule, nespresso, Lavazza, dolce gusto etc. make sure they have enough Nitrogen in cups or bottles.
All the function can be changed according to customer's requirements.
YD300 Liquid Nitrogen Dosing Speed 300cans/min
Could set continuous dosing speed
Apply to all different sizes pet bottles and thin-wall zip-top cans production line, also can use for coffee packing machine, such as K-cup coffee capsule, nespresso, Lavazza, dolce gusto etc.
* Vacuum liquid nitrogen heat insulation pipe ensures the minimum liquid nitrogen consumption.
* Dosing quantity will plus or minus according different speed, feedback to ensure dosing consistency.
*Front temperature monitoring function is plus or minus liquid nitrogen dosing quantity automatically according to the changes of filling temperature, This is a important function, and no import device is with this function for now
*Advanced dosing valve ensures transport pure and liquid nitrogen.
* Lowest outlet pressure of dosing valve ensures minimum liquid nitrogen splash.
* No frost operating condition, 24 hours working without ice blockage with continuous power and liquid nitrogen.
*Dosing Time could correct to 1MS during operation process.
* Continuous self-monitoring through alarm indicator
* Chinese and English for optional in touch screen
* Small size and simple installation.
* Precise control liquid nitrogen dosing
* User could adjust liquid nitrogen dosing easily through micro-adjustment button in touch screen while it is running
* Could be used in continuous production for twenty-four hours
*No container No dosing
* More other speed liquid nitrogen dosing machines for optional to suit other capacity production lines.
Liquid Nitrogen Dosing machine
Specification:
Rated input voltage: 110VAC-60Hz/220VAC-50Hz +/-10%
Electricity: ≤5A
Humidity: Relative humidity 0%-100%
Working altitude: 3050 meters (10000FT) above the sea level
Noisy: Continuous noise≤78dB(A)
Weight: 32KG
Capacity: Max. Speed could reach to 300 cans per min.
Operating Conditions:
1,Supple of Liquid Nitrogen: Regulate to 0.4-0.8Mpa and connect to vacuum pipe.
2,Compressed Air or Nitrogen: Supply to working of dosing valve. The pipe pressure range is from 0.4Mpa to 0.6Mpa.
3,CGA295 connector between liquid nitrogen tank (devar) and vacuum pipe.
Liquid Nitrogen Dosing machine
