Lubricated Lubrication Style and Diesel Power Source Air Compressor Head

Name: Lubricated Lubrication Style and Diesel Power Source Air Compressor Head
Brand: Kaishan
SKU: 127744459
Availability: InStock

US$ 12,300 - 15,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Screw

Configuration:

Portable

Changge Yingchuan Machinery Manufacturing Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai&Ningbo&Qingdao&Tianjin

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Screw

Configuration Portable

Power Source Diesel

Lubrication Style Lubricated

Mute No

Place of Origin Zhejiang, China

Brand Name Kaishan

Model Number LGCY-6/7

Voltage 1

Dimension(L*W*H) 3630*1920*1900mm

Weight 1400kgs

Certification ISO9001:2008

Warranty 3 years except wear out parts

After-sales Service Provided Engineers available to service machinery overseas

Specifications

Lubricated Lubrication Style and Diesel Power Source air compressor head
1.Portable
2.Diesel Driven
3.Screw Type
4.low cost

Lubricated Lubrication Style and Diesel Power Source air compressor head

Thechnical Parameters:

LGCY-6/7 Diesel Driven portable Screw Air Compressor
Model No:	LGCY-6/7 Diesel Screw Air Compressor
Free Air Delivery (m³/min/cfm)	6m³/h
Work pressure(Bar/Psig)	7(102)
Fluid capacity(L)	20
Compression Stage	Single
Diesel Engine:	YUCHAI
Engine Model No.	YCD4B22-95
Capacity (L)	2.977
Rated RPM(r/min)	2500
Unload RPM(r/min)	1800
Rated Power (KW/hp)	70(95)
Fuel capacity(L)	80
Noise level db(a)	80±3
Wheel Size x Qty	5.5-14x2
Dimension/mm	363019201900
Weight(KG)	1400

Package	Polyethylene package and bubble foam
Delivery time	About 20 working days after payment
Warranty	One year for the compressor and three years for the air end (not including quick-wear parts).
Payment term	30% T/T in advance, 70% T/T before the shipment.
