Synthetic Diamond Reaming Shells With Core Bit For Mining Exploration

Synthetic Diamond Reaming Shells With Core Bit For Mining Exploration thumbnail-1
Synthetic Diamond Reaming Shells With Core Bit For Mining Exploration thumbnail-2
Synthetic Diamond Reaming Shells With Core Bit For Mining Exploration thumbnail-3
Synthetic Diamond Reaming Shells With Core Bit For Mining Exploration photo-1
Synthetic Diamond Reaming Shells With Core Bit For Mining Exploration photo-2
Synthetic Diamond Reaming Shells With Core Bit For Mining Exploration photo-3
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
SINOCOREDRILL
Model Number:
BWL NWL HWL PWL
Contact Supplier Request Quote Chat Now
Lianyungang Forward Heavy Industrial Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name SINOCOREDRILL
Model Number BWL NWL HWL PWL
Type Other, REAMER SHELL
Material Other, DIAMOND AND ALLOY STEEL
Use Other, MINING

Synthetic Diamond Reaming Shells With Core Bit For Mining Exploration



Product introduction



 Reaming shell is set with natural or synthetic diamond, and it is used to couple the drill bit with the core barrel. Its main function is to ream the hole to the correct constant specific diameter which ensures adequate clearance for the core barrel and sufficient clearance for the new bit which replaces an old one. It also acts as a stabilizer for drill bit.





Specifications



 Diamond reaming shell

  • Be used together with core bit
  • Protect borehole without hole shrinkage
  • Long service life
  • Adopt first level diamond material
  • First level quality and good price
  • Over 20 years Experience



Reaming shells (with double pads or three pads) are suitable to use in all formation conditions ranging from broken and abrasive to consolidated and non-abrasive. As this kind of reaming shell is physically longer than the standard type, it is necessary to use an appropriate inner tube extension in order to compensate for the difference in overall reaming shell length.

Specialisted in producing varies kinds of diamond core bits in different international standard size for soft, medieum to hard rock formations.

 With ISO certificate & quality control.




Technical Parameters


Core Barrel

Specification



Reaming Shell





Maximum

Minimum

lnch

mm

lnch

mm

A

1.895

48.13

1.885

47.88

B

2.365

60.07

2.355

59.82

N

2.985

75.82

2.975

75.57

H

3.79

96.27

3.775

95.89

P

4.835

120.81

4.82

122.43

T2-101

3.994

101.44

3.984

101.19

T6-101

3.996

101.51

3.984

101.21




WLSeries  BWL NWL HWL PWL
T Series T36, T46, T56, T66, T76, T86, TEW, TBW, TNW
WF Series HWF, PWF, SWF, UWF, ZWF
 WT Series  RWT, EWT, AWT, BWT, NWT, HWT (Single Tube/Double Tube)
 WG Series:  EWG, AWG, BWG, NWG, HWG (Single Tube/Double Tube)
 WM Series  EWM, AWM, BWM, NWM
 T2/T6 Series  T256, T266, T276, T286, T2101/T676, T686, T6101, T6116, T6131, T6146, T6H
 Others  NMLC, HMLC,3C,4C,6C TNW
