Four Column Radiators

Specifications

No edges and corners, easy to clean; upright column structure, good decoration

The Earl cast iron radiator is a victorian cast iron radiator available in four heights which are 460mm, 660mm, 760mm and 813mm.

The specifications are as the followings:

Four column cast iron radiator 4/460

Foot section height 460mm, Middle section height 382mm;

Width 143mm;

Length 60mm;

Central distance is 300mm;

Foot section weight 3.5Kgs, Middle section weight 3.1Kgs;

Water content 0.5L;

Heat Output 80Watts/section;

Working Pressure:0.8-1.0Mpa.

Four column cast iron radiator 4/660

Foot section height 660mm, Middle section height 582mm;

Width 143mm;

Length 60mm;

Central distance is 500mm;

Foot section weight 4.8Kgs, Middle section weight 4.4Kgs;

Water content 0.85L;

Heat Output 116.5Watts/section;

Working Pressure:0.8-1.0Mpa.

Four column cast iron radiator 4/760

Foot section height 760mm, Middle section height 682mm;

Width 143mm;

Length 60mm;

Central distance is 600mm;

Foot section weight 5.6Kgs, Middle section weight 5.2Kgs;

Water content 0.93L;

Heat Output 134Watts/section;

Working Pressure:0.8-1.0Mpa.

Four column cast iron radiator 4/813

Foot section height 813mm, Middle section height 725mm;

Width 160mm;

Length 60mm;

Central distance is 642mm;

Foot section weight 6.4Kgs, Middle section weight 6.0Kgs;

Water content 1.15L;

Heat Output 151.8Watts/section;

Working Pressure:0.8-1.0Mpa.
