Impregnated Diamond Core Drill Bits BWL NWL HWL PWL Longlife for Mining photo-2
Impregnated Diamond Core Drill Bits BWL NWL HWL PWL Longlife for Mining photo-3
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
SINOCOREDRILL
Model Number:
BWL NWL HWL PWL
Contact Supplier Request Quote Chat Now
Lianyungang Forward Heavy Industrial Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin China
Brand Name SINOCOREDRILL
Model Number BWL NWL HWL PWL
Type Core Drill Bit
Material Diamond
Use Other, Mining Exploration

Impregnated diamond Core Drill Bits BWL NWL HWL PWL  Longlife for mining





FACE DISCHARGE WATERWAYS (FD)



 Recommended for very soft and broken ground or swelling core applications with Q barrels. The face discharge ports offer excellent flushing to prevent blockages in the waterway channels by reducing pressure to the ID and redirect fluid to the face of the bit. Also available in WIDE waterway configurations.



Specifications

1. with face discharge holes
2. stable quality,full range of products
3. delivery timely
4. used for mining






Size:


Longlife  diamond core bits are available in all standard drilling sizes . Also, non-standard sized bits can be produced according to requirements from clients.





Crown Height:


We could offers crown impreg depths of  9mm, 12mm, and 16mm .The taller crown heights provide improved bit stability and reduced vibrations, enhancing bit life and performance.



Waterways:
Various waterways are available for diamond impregnated bits. Differing waterways allow for better flu

shing in various ground conditions and drilling systems.

Matrix:
The impregnated bits matrices can be selected by our engineer according to ground conditions at client's work site.



Threads:
standard WL threads as well as thread types required by clients are available.



Series number

Rock

11

magnetit,metamorphschist,gneiss,granite,basalt,gabbro,rhyolite,diorite,conglomerate,taconite

10

magnetit,metamorphschist,gneiss,granite,basalt,gabbro,rhyolite,diorite,conglomerate,taconite

9/10

andesite,pegmatite,hematite,magnetit,metamorph schist,gneiss,granite,basalt,gabbro,rhyolite,diorite

9

andesite,pegmatite,hematite,magnetit,metamorph schist,gneiss,granite,basalt,gabbro,rhyolite,diorite

8

dolomite,marble,peridotite,andesite,pegmatite,hematite,magnetit,metamorph schist,gneiss,granite,basalt

7/8

dolomitic limestone,schist,serpentine,hard & mica schist,siliceous limestone,dolomite,marble,peridotite,andesite,pegmatite,hematite

7

dolomitic limestone,schist,serpentine,hard & mica schist,siliceous limestone,dolomite,marble,peridotite,andesite,pegmatite,hematite

6/7

med-hard limestone,hard limestone,hard shale,dolomitic limestone,schist,serpentine,hard & mica schist,siliceous limestone,dolomite,marble,peridotite

6

med-hard limestone,hard limestone,hard shale,dolomitic limestone,schist,serpentine,hard & mica schist,siliceous limestone,dolomite,marble,peridotite

5

claystone,sandy limestone,soft schist,med-hard sandstone,siltstone,alluvial deposits,calcitic limestone,med-hard limestone,hard limestone,hard shale,dolomitic limestone

4

claystone,sandy limestone,soft schist,med-hard sandstone,siltstone,alluvial deposits,calcitic limestone,med-hard limestone,hard limestone,hard shale,dolomitic limestone

3

soft shale,chalk,marly shale,med-hard limestone,salt,frozen soil&ice,soft sandstone,sandy shale,claystone,sandy limestone,soft schist,med-hard sandstone,siltstone,alluvial deposits,calcitic limestone

2

soft shale,chalk,marly shale,med-hard limestone,salt,frozen soil&ice,soft sandstone,sandy shale,claystone,sandy limestone,soft schist,med-hard sandstone,siltstone,alluvial deposits,calcitic limestone

1

sand,soft shale,chalk,marly shale,med-hard limestone,salt,frozen soil&ice,soft sandstone,sandy shale,claystone,sandy limestone,soft schist


 Size Available as followings:
A, B, N, H, P/ B3, N2, N3, NTT, H3, HTT, P3, PTT
T2 series: T2 46, T2 56, T2 66, T2 76, T2 86, T2 101
T6 series: T6 76, T6 86, T6 101, T6 116, T6 131
T series: T36, T46, T56, T66, T76, T86
Non-standard also can be made as your demand

 Impregnated diamond Core Drill Bits BWL NWL HWL PWL Longlife for mining



Impregnated diamond Core Drill Bits BWL NWL HWL PWL Longlife for mining



Impregnated diamond Core Drill Bits BWL NWL HWL PWL Longlife for mining
