Help Center831 Ventilation Pipe Clamp
Related Products
Specifications
831 ventilation pipe clamp1.ISO 9001:2008 certification
2.full range of sizes are available
3.electro zinc plated
This ventilation pipe clamp use for fastening:
Ventilation pipes such as sprial lock seam pipes,acc.to DIN 24145 and DIN 1506.
Properties:
| Material: | steel DD11(material no.1.0332) acc.to DIN EN 10111 |
| Zinc plating: | electro zinc plated,6-8µm |
| Resistance welded nut: | M8 |
| Resistance welded nut: | M10 |
| Locking screw: | combi-slot cheese head screw |
| Locking screw: | hexagon head screw with separate nut |
| Acoustic insulation lining: | material:EPDM;chlorine-free;silicone-free |
| Sound insulation: | for DIN 4109 |
| Temperature range: | -50° to +110°C |
| Hardness: | 45+-5° Shore |
| Fire behaviore: | DIN 4102:class B2 |
Specifications for 831 ventilation pipe clamp:
1.It's safe assembly clamp that used for mounting of cylindrical air channel.
2.EPDM lining for :
(1)Noise reduction up to 15dB level according to DIN 4109
(2)Vibration Reduction
(3)Partial compensation of thermal expansion.
3.Easy and safe assembly through Combi side screws.
4.Electrogalvanized for corrosion protection(6-8 Microns) .
Application:
1.Used for mounting of pipes to the walls (vertical / horizontal),ceilings and floors
2.For Suspending Stationary Non-Insulated Copper Tubing Lines
3.Being fasteners for pipe lines such as heating,sanitary and waste water pipes;to walls,ceilings and floors.
4.Side screws are protected against loss during assemble with the help of plastic washers
Technical data:
Installation:
Insert pipe, press together clamp parts, tighten locking screws
