hydraulic metal good plate rolling machine, BENDING ROLLS
Main Features:
Performance and characteristics of the SW11X-B Mechanical Level down three-roller rolling machine
Its upper roller can lift and two bottom rollers can move horizontally separately or synchronously. Every bottom roller perform functions of bottom roller and side roller in turn, become two types non-symmetrical three-roller rolling plate machine, which can finish pre-bend and roll of thin and thick plate at the same time. It is convenient to roll taper work piece.
Note: the machine that more than 25×2500 adopts discharge by hydraulic connection plate.
Detailed photoes :
Technical Parameter
MECHANICAL LEVEL DOWN THREE-ROLLER ROLLING MACHINE
Modal | Max. plate Thickness (mm) | Max. Pre- Bending thickness (mm) | Max. plate Width (mm) | Roll speed (m/min) | Min. diameter of Max. plate Thickness (mm) | Upper Roller Diamete (mm) | Bottom roller diameter (mm) | Main Motor power (KW) | Weight (ton) | Dimension L×W×H |
SW11X-B-6×2000 | 6 | 4 | 2000 | 5.6 | 380 | 180 | 170 | 5.5 | 4.6 | 3600×980 ×1300 |
SW11X-B-6×2500 | 6 | 4 | 2500 | 5.6 | 450 | 230 | 200 | 7.5 | 5.3 | 5600×1380 ×1450 |
SW11X-B-8×2000 | 8 | 6 | 2000 | 5.6 | 450 | 230 | 200 | 7.5 | 5.7 | 5100×1380 ×1450 |
SW11X-B-8×2500 | 8 | 6 | 2500 | 5.5 | 500 | 240 | 220 | 11 | 7 | 5780×1490 ×1540 |
SW11X-B-8×3200 | 8 | 6 | 3200 | 5.8 | 650 | 260 | 230 | 15 | 8.6 | 6400×1490 ×1540 |
SW11X-B-12×2000 | 12 | 8 | 2000 | 5.5 | 500 | 240 | 220 | 11 | 6.7 | 5240×1490 ×1540 |
SW11X-B-12×2500 | 12 | 8 | 2500 | 5.8 | 650 | 260 | 230 | 15 | 7.7 | 5740×1485 ×1600 |
SW11X-B-12×3000 | 12 | 8 | 3000 | 5.8 | 750 | 300 | 260 | 22 | 12.1 | 6400×1770 ×1700 |
SW11X-B-16×2000 | 16 | 12 | 2000 | 5.8 | 650 | 260 | 230 | 15 | 7.6 | 5240×1485 ×1600 |
SW11X-B-16×2500 | 16 | 12 | 2500 | 5.8 | 750 | 300 | 260 | 22 | 9.4 | 5800×1770 ×1700 |
SW11X-B-16×3200 | 16 | 12 | 3200 | 5.6 | 900 | 340 | 300 | 22 | 16.8 | 6900×1900 ×1750 |
SW11X-B-20×2000 | 20 | 16 | 2000 | 5.8 | 750 | 300 | 260 | 22 | 8.8 | 5300×1770 ×1700 |
SW11X-B-20×2500 | 20 | 16 | 2500 | 5 | 850 | 340 | 300 | 30 | 16.2 | 6140×1900 ×1750 |
SW11X-B-25×2000 | 25 | 20 | 2000 | 5 | 850 | 340 | 300 | 30 | 13.9 | 5640×1900 ×1750 |
SW11X-B-25×2500 | 25 | 20 | 2500 | 4.5 | 950 | 380 | 320 | 37 | 17.6 | 7500×1740 ×1930 |
SW11X-B-30×2000 | 30 | 25 | 2000 | 4.5 | 950 | 380 | 320 | 37 |
| 6800×1740 ×1930 |
SW11X-B-30×2500 | 30 | 25 | 2500 | 4.5 | 100 | 420 | 320 | 45 |
| 7650×1740 ×2100 |
Note: Plate yield limit 245Mpa is benchmark for design, the technical parameters for your reference, if product mend, parameter alter, we will not inform you in addition.
Company Information
1.Company Name: WUXI SHENCHONG FORGING MACHINE Co., Ltd.
2.Machine Brand: SHENCHONG
3.Shenchong is leading manufacturer: plate bending machine, press brake, shearing machine, guillotine machine, rolling machine.
4.Official website: .
Exhibition
Contact information | ||
Map |
| |
| ||
Contact |
| |
Leta WUXI SHENCHONG FORGING MACHINE CO.,LTD. Tel:+86-510-83951655 | ||
