DX6060 mini milling machine cnc cutting and engraving machine for sale
According to your working area, machine could be customized.
We have 300x400mm, 400x400mm, 400x600mm, 600x600mm, 600x900mm, or bigger.
Features........................................................................................................................
1, High quality Taiwan imported HIWIN Linear guide has much longer life 10 times of life-time than round guide
2, High quality Taiwan TBI ball screw is more stable and has much higher precision than the common screw
3, Water cooling spindle or Air cooling spindle for your choice
4, DSP control system, with handle controller,no need to connect computer
5, Cast Iron frame & Welded Steel Structure make it much stronger, Gross weight 490kgs, even 4 people can not move it
6, CNC Tools & Software(Type 3 and Artcam) are given you for free charge
7, Stepper motor or Servo Motor for your choice
Technical Parameters .................................................................................................
NO. | Description | Parameter |
1 | X,Y,Z Working Area | 600mmx600mmx120mm |
2 | Table Size | 720mmX720mm |
3 | X,Y,Z Traveling Positioning Accuracy | ±0.01mm/300mm |
4 | X,Y,Z Repositioning Accuracy | ±0.01mm |
5 | Table Surface | T-slot and vacuum working Table |
6 | Frame | Cast iron Structure |
7 | X,Y, Z Structure | Taiwan TBI Ball Screw, Taiwan HIWIN linear guide |
8 | Max. Power Consumption | 0.8KW |
9 | Max. Rapid Travel Rate | 10000mm/min |
10 | Max. Working Speed | 8000mm/min |
11 | Spindle Power | 2.2 KW water Cooling Spindle |
12 | Spindle Speed | 0-18000RPM |
13 | Drive Motors | Stepper System |
14 | Working Voltage | AC220V/50/60HZ,1Phs |
15 | Command Language | G code |
16 | Operating System | Ncstudio (options:DSP /Mach3 PC Software) |
17 | Computer Interface | USB |
18 | Flash Memory | 128M(U Disk) |
19 | Collet | ER16 |
20 | X,Y Resolution | <0.01mm |
21 | Software Compatibility | Type3/UcancameV9 software/Artcam software |
Details ........................................................................................................................
Taiwan Hiwin linear guide
Taiwan TBI ballscrew transmission
Samples.........................................................................................................................
Our Factory.................................................................................................................
Guaranty.............................................................................................
1.One year quality guaranty, the machine with main parts (excluding the consumables) shall be changed free of charge if there is any problem during the warranty period.
2.Lifetime maintenance free of charge.
3.Free training course at our plant.
4.We will provide the consumable parts at an agency price when you need replacement.
5.24 hours on line service each day, free technical support.
6.Machine has been adjusted before delivery , operation disk is included.
Looking for agents and wholesale from all over the world!
Any questions,please feel free to contact me !
-----------------------------------------------------------------
Jinan Dexian Machinery Co.,Ltd
Jenny Yang
Phone:0086-18615679773 Skype:dexian010
Wechat:18615679773 QQ:18615679773
