Professional manufacturer cnc router machine to cut wood craft
Features of cnc router machine
1. 1.5 KW air cooling spindle (top brand in China), with high precision and strong power.
2. It is good at engraving on brass, aluminum, plastic, acrylic, wood, MDF and other similar materials. With fast speed and high accuracy, and it can meet the demand of all the needs of engraving.
3. It is equipped with the international leading DSP control system (DSP for choice), which could memorize the breakpoint if it happens accident so that to guarantee to process in the other day.
4. With T-slot working table, holding the materials with clamps, you can do variety of high-precision works.
Details of cnc router machine
Technical Parameters of cnc router machine
NO. | Description | Parameter |
1 | X,Y,Z Working Area | 600mmx900mmx120mm |
2 | Table Size | 720mmX1140mm |
3 | X,Y,Z Traveling Positioning Accuracy | ±0.01mm/300mm |
4 | X,Y,Z Repositioning Accuracy | ±0.01mm |
5 | Table Surface | T-slot Table |
6 | Frame | Welded Structure |
7 | X,Y, Z Structure | Taiwan TBI Ball Screw, Taiwan HIWIN linear guide |
8 | Max. Power Consumption | 0.8KW |
9 | Max. Rapid Travel Rate | 10000mm/min |
10 | Max. Working Speed | 6000mm/min |
11 | Spindle Power | 1.5 KW Air Cooling Spindle |
12 | Spindle Speed | 0-18000RPM |
13 | Drive Motors | Stepper System |
14 | Working Voltage | AC220V/50/60HZ,1Phs |
15 | Command Language | G code |
16 | Operating System | DSP(options: Ncstudio/Mach3 PC Software) |
17 | Computer Interface | USB |
18 | Flash Memory | 128M(U Disk) |
19 | Collet | ER16 |
20 | X,Y Resolution | <0.01mm |
21 | Software Compatibility | Type3/UcancameV9 software/Artcam software |
22 | Running Environment Temperature | 0 - 45 Centigrade |
23 | Relative Humidity | 30% - 75% |
24 | Packing Size | 1710mmx1250mmx1585mm |
25 | G.W. | 400kgs |
Application and Samples of cnc router machine
Assembly Processe of cnc router machine
After-sale Service of cnc router machine
Welcome to Visit Our Factory
Welcome to Contact Me!
Looking for agents and wholesale from all over the world!
Any questions,please feel free to contact me !
-----------------------------------------------------------------
