woodworking machine wood working tools multifunction woodworking machine new type machine woodworking
According to your working area, machine could be customized.
We have 300x400mm, 400x400mm, 400x600mm, 600x600mm, 600x900mm,900x1500mm,1200x1200mm, 1200x1800mm or bigger.
Features
This machine is specially designed for making musical instrument like: valine, guitar etc.
It can also be used for working on aluminum, wood, acrylic.etc.
1. Cast iron structure very heavy and stable, Net weight 560kgs.
2. Taiwan TBI ballscrew, makes the machine with high working accuracy.
3. Popular DSP 4 axis control system X,Y,Z axis and rotary axis can work at same time,very powerful function. It also has a hand held controller,with USB interface,doesn't need connect with computer,easy and convenient for every buyer.
4. Rotary device(4th axis),with rotary device, you can work on cylindrical objects.
Technical Parameters
Working area | 900*1500*200mm |
Table | Aluminum profile T-slot working table with PVC protection |
Spindle power | 2.2kw water cooling spindle,24000rpm |
Motor system | Stepper motor system(option:servo motor) |
Control system | DSP 4 axis control, support USB interface |
Transmission | TBI ballscrew from Taiwan |
Linear rail | Taiwan HIWIN linear guide for XYZ axis |
Inverter | 2.2kw FuLing inverter(option:Delta inverter fromTaiwan) |
Driver | Ledshine driver(top brand in China) |
structure | cast iron bed |
Speed | Max travelling speed:6000mm/min |
Max working speed: 5000mm/min | |
Switch | Japanese OMRON Switch |
Cable | Highly flexible towline;fire-resistant double-sheathed cable |
Software | Type3,Artcam |
Package | Plywood case |
Working voltage | AC220V/1PH/50Hz (option:110V) |
Details
Applications
1. Mold industry: various large metalloid mould, especially suitable for automotive foam mold,
wooden ship model, wooden model aviation, rail wooden mold, wooden mold train.
2. Instrument industry 3-d surface engraving and shape cutting of large-scale instruments
3. Sign, plastics, wood, molds, etc
4. Furniture, general woodworking manufacturing
Samples
Our Factory
We are 5 year Gold Supplier and we support Trade Assurance
Guaranty
1.One year quality guaranty, the machine with main parts (excluding the consumables) shall be changed free of charge if there is any problem during the warranty period.
2.Lifetime maintenance free of charge.
3.Free training course at our plant.
4.We will provide the consumable parts at an agency price when you need replacement. 5.24 hours on line service each day, free technical support.
6.Machine has been adjusted before delivery , operation disk is included.
